10
Align each magnet with the
corresponding switch on the
operator for the open and closed
position.
Connect the battery and test for
proper open & close position.
WARNING : If further adjust-
ment is required, always
disconnect battery prior to
relocating the chain magnet.
GATE LIMIT SWITCH INSTALLATION
Factory Hookup
B
L
A
C
K B
L
A
C
K
R
E
D R
E
D R
E
D
B
L
A
C
K
B
L
A
C
K R
E
D O
R
A
N
G
E G
R
E
E
N W
H
I
T
E
B
L
A
C
K B
L
A
C
K
R
E
D R
E
D R
E
D
B
L
A
C
K
B
L
A
C
K R
E
D O
R
A
N
G
E G
R
E
E
N W
H
I
T
E
Left or Right Hand Operation
Apollo’s line of slide gate operators are pre-wired to open the gate to the right and close the gate to the
left (looking from the inside of the property).
If the operator is to be installed on the left side of the drive, use wiring diagram B
A B
operator
Gate in closed position
operator
Gate in closed position
