Digital Access Keypad Manual
SECO-LARM U.S.A., Inc.
Digital Access Keypad Manual
Note: After entering
programming mode,
proceed to desired
programming option
• 12-24V AC/DC universal power -- No programming or jumpers needed.
• Mantrap -- Each keypad can be used as a stand-alone keypad. However, the mantrap
feature uses two keypads to protect an area with two doors by ensuring that only one
door is open at a time. With the mantrap interlock functions, when a user keys in the
code to open one door, a signal is sent to disable the second keypad, thereby
preventing access through the second door until the first door is closed.
• Relay output #1 inhibit control -- Relay output #1 is typically used for a door strike.
If the keypad is set to the "inhibited" mode, relay output #1 will not operate. This
increases the security of the protected premises during the time it is not expected to
be occupied, such as during evening or weekend hours. An authorized user can
enable or disable the inhibit control by using the code for relay output #2 at any time,
depending on how installed.
• Door-forced-open warning -- When used with an optional magnetic contact, the
keypad beeps continuously if the door to the protected premises is forced open
without using a valid user code. The warning can be stopped only by closing the
protected door.
• Door-propped-open warning -- When used with an optional magnetic contact, the
keypad beeps continuously if the door is propped open after the allowed open time.
The allowable open time is programmable. The warning stops when the door is
re-closed.
• Door-hold-open mode -- Output #2 can be programmed to hold the door open if it
needs to remain open for an extended length of time.
• Auto or manual code entry checking:
• Auto code entry checking mode -- When all the user codes have the same number
of digits, the keypad will activate automatically when the code is entered. There is
no need to press the "#" key. This is convenient for the users.
• Manual code entry checking mode -- The user codes can vary in number of digits,
and the user must press the "#" key when finished entering the code. This
increases security.
• Keypad active output -- This NPN transistor open collector ground (-) output
activates for 10 seconds when any key on the keypad is pressed. This can be used to
trigger a video recorder or turn on a light, or to signal a guard that someone is
entering the protected premises.
• Door auto relock -- The keypad will relock an open door either when the relock time
expires or immediately after the door is closed, depending on which occurs first. This
prevents unwanted "tailgate" entries, which can happen if an unauthorized person
tries to follow an authorized person through the door.
• Duress output -- This NPN transistor open collector ground (-) output can be used to
trigger a silent alarm if an authorized user is forced under duress to use the keypad.
The duress output is activated by adding 2 to the first digit of user code 1. In this
case, the protected door opens as it would normally, but a signal is quietly sent to a
remote device to call for help without alerting the unauthorized person.
• Backlit keypad -- The keypad is backlit to increase nighttime visibility. The backlit
function can be programmed via a jumper for full, partial or no illumination.
UNIQUE FEATURES
(DEFAULT: )
X X X X *
0 0 0 0
*
# 8 9 0 1
#
#
4 0
4 1
#
#
5 0
#
#
7 0
7 1
7 2
7 6
#
#
8 0
1
0
#
#
8 1
1
0
Confirm
#
#
8 2
1
0
#
#
8 3
1
0
#
#
9
#
#
0 0 0 0
*
#
#
5 1
0 0
#
#
8 4
1
0
Enter Master code
*Key in the Master Code.
Note: For first-time use, Master code is
Confirm Function
Enter into programming mode
Enter Programming Mode
Configure Relay Outputs
Option Output ime
1 to 999
Confirm Function
Relay #1, momentary mode, from 1 to 999 seconds
Relay #1, shunt mode (ON/OFF)
INSTALLER PROGRAMMING
These functions should only be used by professional installers, as incorrect entries can disable the entire keypad function.
Relay #2, momentary mode, from 1 to 999 seconds
Wrong Code Lockout
Option # of tries
5 to 10
Confirm Function
After 10 successive wrong codes, 30-second lockout
After 10 successive wrong codes, Duress activated
After 5 to 10 wrong codes, 15-min. lockout - Can reset wi h Master Code
None of the above
Door-Forced-Open Alarm
Op ion Code entry Confirm Function
Door-forced-open alarm is enabled
Door-forced-open alarm is disabled
Door Unlocked Announcer
Option Code entry Confirm Function
1-sec. beep notifies the user to open the door when the output relay is ac ivated.
The beep is disabled, replaced by 2 short beeps for valid user codes.
User Code Entry Mode
Function
Auto Entry Mode is selected. The key that follows he user code is NOT required in
code entry. The User Codes MUST be set to he same digit length as he Master Code.
Manual Entry Mode is selected. The key that follows the user code is required in
code entry. The User Codes can be 4-8 digits, but not necessarily all of the same length.
Keypress Beeps
Op ion Code entry Confirm Function
Keypad beeps when a key is pressed.
Silent operation -- keypad does not beep when a key is pressed.
Door-Propped-Open Alarm Timer
Code entry Confirm Function
No door-propped-open alarm
Allowable time from 1 to 999 seconds that the door can be left open before the alarm starts.
Exit Programming Mode
Function
Exits programming mode, returns keypad to normal operations
(DEFAULT: Momentary, 1-sec. output for both outputs)
(DEFAULT: 10 tries / 30 seconds)
(DEFAULT: Disabled)
(DEFAULT: On)
{
{
(DEFAULT: Manual)
(DEFAULT: On)
(DEFAULT: Off)
Data Refresh
Op ion Confirm Function
Clears all previously stored data.
1 to 999
{
Op ion Code entry {
0
1 to 999
Confirm
Relay #2, shunt mode (ON/OFF)
{
LED Flashes in Standby Mode
Code entry Confirm Function
Amber LED ON during standby mode.
Amber LED OFF during standby mode.
{
(DEFAULT: On)
