CTEK Battery Analyzer User Manual
Page 2
4 • EN
20018478B
BATTERY RATING COMPARISON TABLE
Use this table to compare your reading with other popular battery standards. See battery
label for details or contact your battery supplier for guidance.
BATTERY TEST RESULTS
BATTERY GOOD
Return the battery to service. No action required.
GOOD / RECHARGE
Fully charge the battery and return to service.
CHARGE & RETEST
Fully charge the battery and retest.
(Fully charge the battery before retesting to ensure accurate readings).
REPLACE BATTERY
Test results indicate that the battery is failing and should be replaced.
SPECIFICATIONS
BATTERY VOLTAGE MEASUREMENTS
(Operating Voltage Range: 8.0 V to 15.0 V)
Minimum (V)
Maximum (V)
Resolution (V)
Accuracy (V)
8
15
0.1
±0.1
MEASUREMENTS
Model
Range
Resolution
Accuracy
EN
200–1200 EN
25
±25
US
200–1200 CCA
25
±25
SAE/CCA
EN
EN2
IEC
DIN
200
180
175
130
110
250
230
220
160
140
300
280
265
195
170
350
330
310
225
200
400
360
350
260
225
450
420
400
290
255
500
480
440
325
280
550
520
485
355
310
600
540
530
390
335
650
600
570
420
365
700
640
615
450
395
750
680
660
485
420
800
760
705
515
450
850
790
750
550
480
900
860
790
580
505
950
900
835
615
535
1000
940
880
645
560
1050
1000
925
680
590
1100
1040
970
710
620
1150
1080
1010
745
645
1200
1150
1055
775
675
Note: Non-Automotive AGM models may read higher than actual. Readings will be
consistent between like models.
