HDMI Matrix Switcher
13
10. Specification
Video Input Video Output
Input HDMI Output HDMI
Input
Connector
HDMI 1.3 Output Connector HDMI 1.3
Input Level T.M.D.S. 2.9V/3.3V Output Level T.M.D.S. 2.9V/3.3V
Input
Impedance
75Ω
Output Impedance
75Ω
Video General
Gain 0 dB Bandwidth 340 MHz (10.2 Gbit/s)
Video Signal HDMI (or DVI-D) Maximum Pixel Clock 165MHz
Resolution
Range
Up to 1920 x 1200 or
1080P@60Hz
Switching Speed 2 – 5 seconds
Consumer
Electronics
Control
(CEC)
Supports CEC wired infrared data pass-through using the HDMI 1.3 standard
EDID and
DDC
Management
Supports Extended Display Identification Data (EDID) and Display Data Channel (DDC)
data using DVI and HDMI standards, EDID and DDC signals are actively buffered. The
built-in EDID/DDC database can analyze these two signals, mix them, and realize the
handshake of them internally.
HDCP
Management
Compliant with High-bandwidth Digital Content Protection (HDCP) using DVI and HDMI
1.3 standards. The built-in HDCP management technology can analyze HDCP key, and
realize the handshake internally.
Audio General
Digital Audio Supports HDMI audio transmitted through the RGB and Y, Cr, Cb lines, actively buffered
Control Parts
Serial
Control Port
RS-232, 9-pin female D
connector
Pin Configurations 2 = TX, 3 = RX, 5 = GND
IR Remote Default IR remote Front Panel Control Buttons
Options TCP/IP control by PTNET(PTN's programmable interface)
General
Power
Supply
100VAC ~ 240VAC, 50/60Hz Power Consumption 60W
Temperature -20 ~ +70
℃
Humidity 10% ~ 90%
Case
Dimension
W483 x H310 x D320mm
(4U high, full rack wide)
Product Weight 16Kg
