6.2.3 EDID restore to factory default
EDID management by RS232 command
When we send the “EDIDMInit.” to the MHD matrix switcher, it will recover the factory default EDID data.
The feedback command is “EDIDMInit”.
6.2.4 Manually EDID switching
EDID management by RS232 command
When we send the RS232 command “EDIDM[X]B[Y].”. The matrix will copy the EDID data of output[X]
to the input[Y]. The feedback command is “EDIDM: [X]To[Y]”.
6.3.5 RS232 feedback:
When a RS232 command is correctly sent, all the connected displayers will be blank for 2~3 seconds
and recover again. And, the MHD matrix switcher will send out the RS232 feedback command.
If all these symbols works, it means the action is taken.
6. Operation of the Control Panel
7.1 Front Panel Description
Buttons Function Description
INPUTS Input buttons. It is the number of every input channel, ranging from "0" to "9".
OUTPUTS Output buttons. It is the number of every output channel, ranging from "0" to "9".
AV
AV synchronal button: To transfer video and audio signal synchronously by the switcher.
Operation: Press buttons in this order “AV”, “3”, “4”.
,
Division button: to divide the output channels when switching to more than one channel.
Example: To transfer input 1 to output 1,8,15, you need to press this button between
each two output channels.
ENTER
Confirmation button: Confirm the switching operation. The operation will not be executed
by the matrix without confirmation.
ALL
All button: To transfer an input channel to all output channels or switch off all the output
channels
Example1: To transfer video and audio signals from input channel No.12 to all output
channels
Operation: Press buttons in this order “12”, “ALL”
Example2: To transfer all input signals to the corresponding output channels
respectively. In another word, to switch to this status: 1->1, 2->2, 3->3, 4->4…16->16…
Operation: Press buttons in this order “ALL”, “THROUGH”
THROUGH
Through button: To transfer the signals directly to the corresponding output channels
Example: To transfer the signals from input channel No. 3 to their corresponding output
channels
Operation: Press buttons in this order “3”, “THROUGH”
