6.2.2 The PICTURE Menu
Table 5 defines the PICTURE menu.
Table 5: The PICTURE Menu Features
Parameter Function Range Default
CONTRAST Adjust the contrast From 0 to 63 58
BRIGHT Adjust the brightness From 0 to 63 31
COLOR Adjust the color From 0 to 63 31
HUE Adjust the hue From 0 to 63 31
DETAIL Adjust the sharpness From 0 to 63 10
RESET Select RESET and press ENTER to reset to the default parameters
EXIT Select to exit to the MAIN MENU
6.2.3 The SETUP Menu
Table 6 defines the SETUP menu.
Table 6: The SETUP Menu Features
Parameter Function
ASPECT 1 Select between STANDARD, 4:3 and 16:9
OUTPUT Select a PC (RGB) output or an HDTV (Y, Pb, Pr) output
3D ENHANCE Turn the 3D comb filter function ON or OFF 2
DIGITAL NR Turn the digital noise reduction function ON or OFF
DISPLAY Set to ON to display the input standard and the output resolution on the screen;
otherwise, set to OFF
HV OUTPUT Select ON to send H and V synchronization when Y, Pb, Pr is selected for the output 3
EXIT Select to exit to the MAIN MENU
1 STANDARD will output the signal in the same aspect ratio as the input aspect ratio. 4:3 and 16:9 will always output as 4:3
and 16:9 respectively, regardless of the input aspect ratio
2 When a video player or a non-standard video source is connected to the input, the output picture may jitter. If this occurs,
turn the 3D Comb Filter to OFF
3 H and V are always sent when RGB is selected at the output
