Comprehensive CSC-550 - Manual (Page 10)

8
6.3 Controlling via the Infra-Red Remote Control Transmitter
You can control the CSC-550 from the infra-red remote control transmitter,
as Figure 3 and Table 7 define:
Table 7: Infra-Red Remote Control
Transmitter Functions
Keys Function
POWER Turn power ON or OFF
DISPLAY Turn input standard and output
resolution information display ON or
OFF
C-VIDEO Select the composite video input
S-VIDEO Select the s-Video input
YCbCr Select the component video input
PC Select the input PC to loop-through
VGA Set the output resolution to 640x480
SVGA Set the output resolution to 800x600
XGA Set the output resolution to 1024x768
SXGA Set the output resolution to
1280x1024
480p Set the output resolution to 852x480p
576p Set the output resolution to 852x576p
720p Set the output resolution to
1280x720p
1080i Set the output resolution to
1920x1080i
ASPECT Select the standard, normal (4:3) or
the wide (16:9) aspect ratio
RESET
Press and hold for 2 seconds to reset
all the ProcAmp settings (contrast,
brightness and so on) 1
3D Turn the 3D enhance feature ON or
OFF
NR Turn the digital noise reduction feature
ON or OFF
MENU Enter the OSD menu
ENTER Press to accept changes and to
change SETUP parameters
Press to adjust the picture parameters
Figure 3: Infra-Red Remote Control
Transmitter
1 In some versions, you need to be within the PICTURE menu to do this
MENU
NR
PC
YPbCr
S-VIDEO
C-VIDEO
3D
RESET
ASPECT SXGA
SVGA VGA XGA
576p 720p 1080i
480p
ENTER
