5.2 OUTPUT SIGNAL FAILS TO INCREASE
WITH ADDED LOAD
The transducer is overloaded and is hitting the
mechanical stop. Replace the transducer with one
having a higher maximum working force or reduce the
load. (This may be accomplished by reducing the web
wrap angle.)
5.3 WRONG POLARITY OF OUTPUT
SIGNAL
Transducer may have been incorrectly oriented. Make
certain that the web force is being applied to the top side
of the transducer which is identified by the load line label
as shown in Figure 2 on page 3. If rotation is impossible,
interchange the transducer leads as instructed in the
tension indicator or controller manual.
5.4 NO OUTPUT SIGNAL
Check to see that all connections have been made
completely. Check for places where the connecting
cable might be crimped or cut.
5.5 VERY HIGH OUTPUT WITH NO LOAD
Check cable and connector for good connections and
check continuity of cable with an ohmmeter. Check for
proper wiring to transducer. Check transducer gage
resistance as given in the following chart at room
temperature with no load applied.
TRANSDUCER GAGE RESISTANCE CHECK
Size 1T, 2T Steel
Measurement Resistance
Pin B to Pin C 440 ohms ±72 ohms
Pin A to Pin B 700 to 1400 ohms
Pin A to Pin C Equal to Pin A
to Pin B ±12 ohms
Size 1T (Aluminum)
Measurement Resistance
Pin B to Pin C 440 ohms ±72 ohms
Pin A to Pin B 220 ohms ±36 ohms
Pin A to Pin C Equal to Pin A
to Pin B ±12 ohms
6.0 SERVICE ASSISTANCE AND
REPAIR
For additional service assistance, please obtain the Type,
MWF, and Serial Number from the nameplate. Contact
the Factory Service Department.
Phone: (216) 524-8800
Fax: (216) 642-2100
Disassembly by improperly trained personnel may result
in additional damage to these units. Should repairs be
required or for warranty repairs, contact the Customer
Service Department for a return authorization number
before returning the unit.
