Installation
Page 9 Manual BÜHLER BU4010ff
for bottle variants: 2 x 10 L, 4 x 5 L, 12 x 1,6 L
• 1400 (2175*) x 800 x 850 mm
for bottle variants: 4 x 10 L, 24 x 1 L, 24 x 2 L
*) with opened top
Weight 115 kg with bottle option 2x10 L PE; higher weight when using other
bottle or glass bottle options
Device designation
6010 (like 4010, with the following modifications)
Device type Fixed site sampler in double-housing (measuring station)
Measuring pot inlet Hose nozzle ½“, hose ID 12 mm
Measuring pot outlet Hose nozzle ID 40 mm. The customer has to make sure that the water
in the measuring pot can drain off freely
Bottle variants Plastic
1 x 25 L, 1 x 50 L, 2 x 10 L
4 x 6,0 L, 4 x 10 L, 4 x 14 L,
12 x 2,9 L, 24 x 1,0 L
Glass
12 x 2,0 L, 24 x 1,0 L
Overall dimensions (Hxwxd)
1.690 (2290*) x 1280 x 645 mm
*) with opened top
Weight Approx. 250 kg with composite container; higher weight when using
several bottles and/or glass bottles
Power requirement Approx. 450 VA (with cooling + SC1000 controller), higher requirement
when using the optional spiral pump
Device designation
3010 (like 4010, with the following modifications)
Device type Compact device in plastic housing, especially suitable for high ambient
temperatures. Material: PE with 50 mm insulation / Styrosun / PC
(GF10)
Suction height Max. 7,5 m (at 1013 hPa and stagnant medium)
Pumping speed >0,5 m/s at suction height up to at least 6 m (at 1013h Pa); pump
capacity can be adjusted electronically
Suction hose PVC, L=7,5 m, ID=10 mm (ID 16 mm at flow-proportional option).
Max. hose length 30 m
Bottle variants Plastic
1 x 25 L, 4 x 14 L, 12 x 2,9 L, 24 x 1,0 L
Glass
12 x 2,0 L, 24 x 1,0 L
Sampling method Vacuum system 20-350 ml with plastic metering vessel
Ambient temperature -20°C to + 50°C (tropicalised)
Overall dimensions (Hxwxd)
1.100 (1.640*) x 760 x 745 mm
*) with opened top
Weight Approx. 70 kg with composite container, higher weight when using
several bottles and/or glass bottles
