Installation
Page 8 Manual BÜHLER BU4010ff
*) with opened top
Weight 100 kg with composite container; higher weight when using several
bottles and/or glass bottles
Power supply 230 V 50Hz
optional 115 V 50/60Hz
Power requirement Approx. 350 VA (with cooling)
Ambient temperature -20 - +43°C
Sample temperature 0 – 40°C
Standards Device meets ISO 5667 standard
Wetted materials PVC, Silicone, PS, PE, EPDM (optional: glass (Duran50) metering
vessel, sinker weight SS304)
Device designation
4210 (like 4010, with the following modifications)
Device type Fixed site sampler for sampling of faecal matter
Rinsing water inlet
Rinsing water outlet Union nut R 3/4" (max. 2 bar)
Hose connector 25 mm
Sampling method Vacuum system 20-500 ml
Sampling modes Time-related, flow-dependent, event-related, manual sample extraction
Bottle variants Plastic
1 x 25 L, 4 x 14 L, 4 x 20 L
12 x 1 L, 23 x 1,0 L
Glass
12 x 1,0 L, 23 x 1,0 L
Sample distribution Direct distribution with additional position for rinsing water. When using
the rinsing function, the customer has to make sure that the rinsing
water can drain off freely
Overall dimensions 1.290 (1.890*) x 690 x 645 mm
for bottle variants: 1x25 L, 4x14 L, 12x1 L
1400 (2015*) x 930 x 850 mm
for bottle variants: 4x20 L, 23x1 L
*) with opened top
Weight 105 kg with composite container; higher weight when using several
bottles and/or glass bottles
Device designation 4410 (like 4010, with the following modifications)
Device type Self-emptying fixed site sampler for continuous operation without the
need of personnel (monitoring applications)
Emptying/rinsing Bottles are emptied, rinsed and re-filled on the same bottle position.
The rinsing head is installed above the bottle.
Bottle emptying for sample
collection According to the device version: manual bottle emptying at 12 and 24-
bottle version or menu-driven emptying at 2 and 4-bottle version
Hose inlet Hose connection at dosing unit (top)
Union nut R 3/4", hose ID 12 mm
Hose outlet Hose connection at dosing unit
Silicone hose 12x2, is only slipped over
Rinsing water inlet Union nut R 3/4" (max. 2 bar)
Rinsing water outlet Union nut R 1 1/4". When using the rinsing function, the customer has
to make sure that the rinsing water can drain off freely
Bottle variants Plastic
2 x 10 L, 4 x 5 L, 4 x 10 L, 24 x 2 L (PPH)
Glass
12 x 1,6 L, 24 x 1,0 L, 24 x 2 L
Overall dimensions (Hxwxd)
• 1.290 (1930*) x 690 x 645 mm
