30
Operation
5.2
Menu level 1 Menu level 2 Menu level 3 Description
+SETTINGS 
for parameterizing the
instrument
Language Option to select the language for the menus
HEATER Self-adjusting pipe trace heater —
turn on if there is a risk of freezing!
Interval
Time interval (6–60 minutes) between
2 samples.
An interval > 12 minutes is only necessary for
longer analysis periods
Probe type Length of connection tube (10–30 m
(393.7–1181.1 in)
Contrast Reading angle (0–30) of the display;
temperature dependent
press. indic.
Pressure display on the screen; can be
switched off
Version Instrument type and program version
+OUTPUT TEST 
for testing 
connected 
data cables
error indication
Switches on the potential-free fault indication
contact for 2 seconds
The fault indication contact is only held in
the previous position for as long as the
user activates it for testing purposes.
fiber optic 1
Blanks fiber optic cable 1 for 1 second
fiber optic 2
Blanks fiber optic cable 2 for 1 second
OF output 2
+SERVICEMENU

for maintenance tasks
and functional tests
+INSPECTION:
SIGMATAX switches to
service mode
clean.samp. tube
Cleans the sample tube (assisted by the
program)
cleaning probe
Cleans the sampling probe (assisted by the
program)
blowing probe
Automatically cleans the sampling probe with
air
blowing valve Automatically cleans the drain valve with air
+FUNCTIONSTEST 
SIGMATAX switches 
to service 
mode
compressor Activates compressor for 30 seconds
probe valve
Automatically open and close the 
probe valve
ultrasonic
Takes a new sample and activates 
ultrasound for 30 seconds
drain valve
Automatically opens and closes the drain
valve
+ERROR STATUS filling error Counter for filling errors that have occurred
delivery error Counter for delivery errors that have occurred
error reset Reset the counters to "0"
Menu overview
