Hach-Lange POLYMETRON 8350_8351 User Manual User Manual
Page 8

4/6
• VIA THE 08350=A=8000 PRE-AMPLIFIER UNIT
It is impossible to connect the liquid earth in this case.
Ext.
Shielding
white
pink
yellow
brown
grey
green
Input (pH/rH)
- V
+ V
Ref. (Reference)
Temp + (Pt 100)
Temp - (Pt 100)
EMC
protection
EMC
protection
Input (pH/rH)
Ref. (Reference)
Temp + (Pt 100)
Temp - (Pt 100)
white
red
black
Clear
Ext.
Shielding
2666 cable
08350=A=8000 Pre-amplifier
Probe
• USING THE 08350=A=8500 JUNCTION BOX
white
red
black
Clear
Probe
Temp + (Pt 100)
Temp - (Pt 100)
Ref. (Reference)
Ext.
Shielding
white
Schielding
Input (pH/rH)
EMC
protection
Core
yellow / green
violet
Liquid earth (contact)
EMC
protection
Liquid earth (contact)
Temp + (Pt 100)
Temp - (Pt 100)
Ref. (Reference)
Input (pH/rH)
Ext.
Shielding
blue
08350=A=8500 Junction box
2654
For pH probes only:
Temperature measurement.
-
Impedance measurement (the blue wire from the transmitter's "liquid earth"): programme the control frequency and the upper and lower
limits (refer to the instructions for the 9135 transmitter):
Glass impedance:
50 Mohm - 500 Mohm
Reference impedance:
1…100 kohm
