17
Operation
4.6 Pressure and Elevation
Note: If the barometric pressure from Table 5 is entered in the meter, the altitude entered in
combination with this value must be 0 feet.
Table 5 can be used to estimate the true barometric pressure at certain elevations. The
correspondence is based on the assumption that at sea level the barometric pressure is
760 mm Hg. After determining the barometric pressure from the table or obtaining it from a
local weather service, enter this value into the instrument.
DIAG/TEST
PROBE INFO
Display the entered name of the sensor, the sensor serial number, the software version number, and the sensor driver
version number.
CAL DATA
Displays the current offset correction and the date of the last calibration.
SIGNALS
SENSOR SIGNAL allows the user to set the sensor range and display the sensor ADC counts and TEMP ADC COUNTS
shows raw data for temperature ADC counts. Comparable to A/D counts.
COUNTERS
SENSOR DAYS displays the cumulative days the sensor has been in use and RESET SENSOR allows the sensor counter
to be reset to zero.
4.5 Sensor Setup Menu (continued)
Table 5 Elevation Barometric Pressure
Elevation in feet Barometric pressure in mm Hg Elevation in feet Barometric pressure in mm Hg
0 760 6000 613
500 746 6500 601
1000 733 7000 590
1500 720 7500 579
2000 708 8000 568
2500 695 8500 559
3000 683 9000 548
3500 671 9500 538
4000 659 10000 527
4500 647 10500 517
5000 635 11000 506
5500 624 — —
