10. Set the sample flow to the required rate (between 5 and 20 L/h).
11. Modify the resin parameters (see

Resin option

on page 11).

Troubleshooting

Controller

Refer to the Troubleshooting section of the controller documentation for detailed information.

Analyzer

Refer to the Troubleshooting section of the conductivity module documentation for detailed
information.

Sensor diagnostic and test menu

The sensor diagnostic and test menu shows current and historical information about the instrument.
Refer to

Table 1

.

Table 1 Sensor DIAG/TEST menu

Option

Description

MODULE INFORMATION

Shows information about the sensor module.

SENSOR INFORMATION

Shows the name and serial number that was entered
by the user.

CAL DAYS

Shows the number of days since the last calibration.

CAL HISTORY

Shows a list of all calibrations by date/time stamp. Use
the arrows keys to select a calibration and push enter
to view the details.

RESET CAL HISTORY

Resets the calibration history for the sensor (requires
service-level passcode). All previous calibration data is
lost.

POLARIZATION

Contacting conductivity sensors only. Shows
information about the electrode polarization, the cable
capacitance and the time before the next
measurement.

SENSOR SIGNALS

Shows the current sensor signal information.

FACTORY CAL

Reserved for service technicians only.

DIAG MEAS

Shows diagnostic information about the current
measurement.

Spare parts and accessories

Note: Product and article numbers may vary for some selling regions. Contact the appropriate distributor or refer to
the company website for contact information.

Description

Item no.

Conductivity probe

08310=A=0000

Cable for 8310 probe (1 meter)

09123=A=8001

Dual measurement cell

09523=C=0100

Sample flow adjustment valve

09184=C=4010

O-Ring for flow regulation valve

429=042=019

14 English
