106
Maintenance and Troubleshooting
14.3 List of events and alarms
Table 4 List of Events
Event
type
Name Description
Bit mask
value (32
bits long)
Information
Measure Normal measurement mode. 0x00000000
Filter enabled The gas measurements are filtered. 0x00000001
Sample measurement The sample measurement is started. 0x00000002
Meas. not ready The measurement is not ready (e.g. at startup) 0x80000000
Autotest in progress The autotest is running. 0x00100000
Autotest failed The autotest has failed. 0x00200000
Alarm snooze The alarm snooze is ON. 0x00000004
Sample mode user
aborted The sample mode has been stopped because the user has pressed the stop
button.
0x00010000
Sample mode stopped
because of time out The sample mode has been stopped because the
maximum time to reach the target has elapsed.
0x00020000
Sample mode stopped
because of an error The sample mode has been stopped because of a measurement error
(sensor out, purge failure, etc.).
0x00040000
W
a
rnin
g
Calibration Channel in calibration. 0x00000008
Hold The measurement is frozen. 0x00400000
Alarm low low The gas concentration below the Alarm LowLow limit. 0x00000010
Alarm low The gas concentration is below the Alarm Low limit. 0x00000020
Alarm high The gas concentration is above the Alarm High limit. 0x00000040
Alarm high high The gas concentration is above Alarm HighHigh limit. 0x00000080
Calibration required The calibration of the sensor is required. 0x00000100
Service required The sensor requires a service. 0x00000200
TC hold TC measurement on hold 0x08000000
Continuous purge on Continuous purge is on 0x10000000
Al
a
rm
Channel disabled The channel has been disabled. 0x00000400
Channel out The measurement board has been disconnected (or does not answer). 0x00000800
Sensor out The sensor has been disconnected. 0x00001000
Ext. pressure sensor
out
The external pressure sensor is out. 0x00002000
Thermal cut off The temperature is above the thermal cut off. 0x00004000
Interfering gas error
For this channel, an interfering gas is taken into account (i.e. O
2
over N
2
).
This interfering gas is measured by another channel. This event occurs
when the other channel:
• is in error (sensor out, thermal cut off, calibration, etc.)
• does not exist anymore
• does not measure the right gas (i.e. O
2
)
0x00008000
PROFIBUS-DP value
not updated The PROFIBUS-DP module has not received
measurements from the instrument for 30 seconds.
0x00080000
Ramp limit violated V3 voltage outside range -3V to +8V 0x04000000
