27
IMPORTANT: The dryer must be connected to the electric supply shown on the data label that is
affixed to the left side panel/wall area behind the control door. In the case of 208
VAC or 230/240 VAC, the supply voltage must match the electric service
specifications of the data label exactly.
IMPORTANT: The wire size must be properly sized to handle the related current.
WARNING: 208 VAC AND 230/240 VAC ARE NOT THE SAME. Any damage done to dryer
components due to improper voltage connections will automatically VOID THE
WARRANTY.
NOTE: ADC reserves the right to make changes in specifications at any time without notice or
obligation.
ADG-25 (GAS)
ADS-25 (STEAM )
ELECTRICAL SERVICE SPECIFICATIONS (PER DRYER)
IMPORTANT: 208 VAC AND 230/240 VAC ARE NOT THE SAME. When ordering,
specify exact voltage.
NOTES : A. When fuses are used they must be dual element, time delay, current limiting, class
RK1 or RK5 ONLY . Calculate/determine correct fuse value, by applying either
local and/or National Electrical Codes to listed appliance amp draw data.
B. Circuit breakers are thermal-magnetic (industrial) motor curve type ONLY . For
others, calculate/verify correct breaker size according to appliance amp draw rating
and type of breaker used.
C. Circuit breakers for 3-phase (3Ø) dryers must be 3-pole type.
SERVICE
VOLTAGE
PHASE
WIRE
SERVICE
APPROX.
AMP DRAW
CIRCUIT
BREAKER
60 Hz 50 Hz
120 1ш 2 9.6 - - 15
208 1ш 2 5.8 - - 15
230/240 1ш 2 5.3 4.4 15
208 3ш 3/4 3.0 - - - 15
230/240 3ш 3 3.2 4.0 15
380-400 3ш 3/4 - - 2.2 15
416 3ш 3/4 - - 2.3 15
460/480 3ш 3/4 2.1 - - 15
