6
SECTION II
SPECIFICATIONS
A. SPECIFICATIONS (AD-25)
* Contact factory for information not listed, 3-phase (3ø) figures shown are for 3-wire service, non-reversing.
** Specify air-operated or electromechanical steam damper system. Air-operated steam damper system must be provided with clean,
dry, and regulated 80 PSI ± 10 PSI (5.51 bars ± 0.68 bars) air supply.
NOTE: ADC reserves the right to make changes in specifications at any time without notice or
obligation.
Gas
Electric
Steam**
MAXIMUM CAPACITY (DRY WEIGHT) 25 lbs 11.3 kg
BASKET (TUMBLER) DIAMETER 32-3/4" 83.2 cm
BASKET (TUMBLER) DEPTH 19" 48.3 cm
BASKET (TUMBLER) MOTOR 1/2 HP 0.373 kw
DOOR OPENING (DIAMETER) 21-1/2" 54.61 cm
BASKET (TUMBLER) VOLUME 9.26 cu.ft. 0.262 cu.m.
DRYERS PER 20'/40' CONTAINER 14/30
DRYERS PER 48'/53' TRUCK 45/51
VOLTAGE AVAILABLE 120-460v 1ш 3ш 50/60 Hz
APPROX. WEIGHT (UNCRATED) 420 lbs 190.5 kg
APPROX. WEIGHT (CRATED) 458 lbs 207.7 kg
HEAT INPUT 78,000 btu/hr 19,650 kcal/hr
AIRFLOW 600 cfm 17 cmm
INLET PIPE CONNECTION 1/2" M.P.T.
OVEN SIZE
KW BTUH KCAL/HR
15 --- 12,900
18 61,450 15,500
20 68,250 17,200
24 81,900 20,650
APPLIED VOLTAGE/PHASE/APPROX. AMP DRAW*
KW 208/1ш 240/1ш 208/3ш 240/3ш 380/3ш 416/3ш 460/3ш
60 Hz 50 Hz 60 Hz 50 Hz 60 Hz 50 Hz 60 Hz 50 Hz 60 Hz 50 Hz 60 Hz 50 Hz 60 Hz 50 Hz
15 -- -- -- -- -- -- -- -- -- 25 -- -- -- --
18 92 -- 80 83 53 -- 47 47 -- -- -- 27 25 --
20 102 -- 89 91 -- -- -- -- -- 33 -- -- -- --
24 -- -- -- -- 70 -- 61 62 -- -- -- 36 32 --
VOLTAGE AVAILABLE 120-460v 1ш 3ш 50/60 Hz
APPROX. WEIGHT (UNCRATED) 448 lbs 203.2 kg
APPROX. WEIGHT (CRATED) 486 lbs 220.4 kg
AIR CONNECTION 1/8" F.P.T.
STEAM CONSUMPTION BOILER HP NORMAL LOAD
98.8 lbs/hr 44.8 kg/hr 2.9
OPERATING STEAM PRESSURE STEAM SUPPLY STEAM RETURN
125 PSI MAX 8.6 bars 1" F.P.T. 1" F.P.T.
Shaded areas are stated in metric equivalents
