8
C. SPECIFICATIONS (AD-50)
* 50 lbs (22.7 kg) reversing dryer available with 3-phase (3ø) motors standard with 1/2 HP (0.37 kw) motors.
** Size of piping to dryer varies with installation conditions. Contact factory for assistance.
*** Contact factory for information not listed, 3-phase (3ø) figures shown are for 3-wire service.
**** Specific air operated or electromechanical steam damper system. Air operated steam damper system must be provided with a
clean, dry, and regulated 80 PSI ± 10 PSI (5.51 bars ± 0.68 bars) air supply.
NOTE: ADC reserves the right to make changes in specifications at any time without notice or
obligation.
MAXIMUM CAPACITY (DRY WEIGHT) 50 lbs 22.7 kg
BASKET (TUMBLER) DIAMETER 32-3/4” 83.2 cm
BASKET (TUMBLER) DEPTH 37-1/2” 95.25 cm
BASKET (TUMBLER) MOTOR 3/4 HP* 0.560 kw
DOOR OPENING (DIAMETER) 21-1/2” 54.61 cm
BASKET (TUMBLER) VOLUME 18.3 cu. ft. 0.518 cu.m.
DRYERS PER 20’/40’ CONTAINER 10/20
DRYERS PER 48’/53’ TRUCK 26/28
VOLTAGE AVAILABLE 120-460v 1ш - 3ш 50/60 Hz
APPROX. WEIGHT (UNCRATED) 635 lbs 288 kg
APPROX. WEIGHT (CRATED) 680 lbs 308.4 kg
ADG-50DR ADG-50D
HEAT INPUT 130,000 btuh 32,760 kcal/hr 150,000 btuh 37,800 kcal/hr
AIRFLOW 600 cfm 17 cmm
INLET PIPE CONNECTION 1/2” M.P.T.**
OVEN SIZE
KW
BTU/HR
(60 H Z )
KCAL/HR
(50 Hz)
20 68,260 17,200
24 81,900 20,640
25 -- 21,500
30 102,390 25,800
APPLIED VOLTAGE / PHASE / APPROX. AMP DRAW***
KW
208/1ш 240/1ш 208/3ш 240/3ш 380/3ш 416/3ш 460/3ш
60 Hz 50 Hz 60 Hz 50 Hz 60 Hz 50 Hz 50/60 Hz 60 Hz 50 Hz 60 Hz 50 Hz 60 Hz 50 Hz
20 108 -- 90 88 -- -- - - -- 33 -- -- -- --
24 -- -- -- -- 70 -- 62 -- -- -- 36 32 --
25 -- -- -- -- -- -- - - -- 40 -- -- -- --
30 -- -- -- -- 86 -- 76 -- -- -- 44 40 --
VOLTAGE AVAILABLE 120-460v 1ш - 3ш 50/60 Hz
APPROX. WEIGHT (UNCRATED) 667 lbs 302.6 kg
APPROX. WEIGHT (CRATED) 710 lbs 322.1 kg
AIRFLOW 600 cfm 17 cmm
COMPRESSED AIR VOLUME 0.75 cfh 0.02 cmh
AIR CONNECTION 1/8” F.P.T.
STEAM CONSUMPTION BOILER HP NORMAL LOAD
142 lbs/hr 64.4 kg/hr 4.1
OPERATING PRESSURE SUPPLY CONNECTION** RETURN CONNECTION**
125 PSI max 8.62 bar 1” F.P.T. 1” F.P.T.
Shaded areas are stated in metric equivalents
Gas
Electric
Steam****
