7
Gas
Electric
Steam**
MAXIMUM CAPACITY (DRY WEIGHT) 30 lbs 13.6 kg
BASKET (TUMBLER) DIAMETER 30” 76.2 cm
BASKET (TUMBLER) DEPTH 30” 76.2 cm
BASKET (TUMBLER) MOTOR 1/2 HP 0.373 kw
DOOR OPENING (DIAMETER) 21-1/2” 54.61 cm
BASKET (TUMBLER) VOLUME 12.27 cu.ft. 0.347 cu.m.
DRYERS PER 20'/40' CONTAINER 12/28
DRYERS PER 48'/48' TRUCK 32/36
VOLTAGE AVAILABLE 120-460v 1, 3ø 50/60 Hz
APPROX. WEIGHT (UNCRATED) 535 lbs 242.7 kg
APPROX. WEIGHT (CRATED) 585 lbs 265.4 kg
HEAT INPUT 90,000 btu/hr 22,680 kcal/hr
AIRFLOW 600 cfm 17 cmm
INLET PIPE CONNECTION 1/2” M.P.T.
OVEN SIZE
KW
BTUH
(60 H Z )
KCAL/HR
(50 Hz)
15 51,200 12,900
20 68,250 17,200
24 81.900 20,650
30 102,390 25,800
APPLIED VOLTAGE/PHASE/APPROX. AMP DRAW*
KW 208/1ш 240/1ш 208/3ш 240/3ш 380/3ш 416/3ш 460/3ш
60 Hz 50 Hz 60 Hz 50 Hz 60 Hz 50 Hz 60 Hz 50 Hz 60 Hz 50 Hz 60 Hz 50 Hz 60 Hz 50 Hz
15 -- -- -- -- 44 -- 39 40 -- -- -- -- -- --
20 102 -- 89 88 -- -- -- -- -- 33 -- -- -- --
24 -- -- -- -- 70 -- 61 62 -- -- -- 36 32 --
30 -- -- -- -- 86 -- 75 76 -- -- -- 44 40 --
VOLTAGE AVAILABLE 120-460v 1, 3ø 50/60 Hz
APPROX. WEIGHT (UNCRATED) 580 lbs 263.1 kg
APPROX. WEIGHT (CRATED) 630 lbs 285.8 kg
AIRFLOW 600 cfm 17 cmm
COMPRESSED AIR VOLUME 0.75 cfh 0.02 cmh
AIR CONNECTION 1/8” F.P.T. 0.318 cm
STEAM CONSUMPTION BOILER HP NORMAL LOAD
104 lbs/hr 47.2 kg/hr 3.0
OPERATING STEAM PRESSURE STEAM SUPPLY STEAM RETURN
125 PSI 8.6 bars 1” F.P.T. 1” F.P.T.
Shaded areas are stated in metric equivalents
B. SPECIFICATIONS (AD-30)
* Contact factory for information not listed, 3-phase (3ø) figures shown are for 3-wire service, non-reversing.
** Specify air operated or electromechanical steam damper system. Air operated steam damper system must be provided with
clean, dry and regulated 80 PSI +/- 10 PSI (5.51 bars +/- 0.68 bars) air supply.
NOTE: ADC reserves the right to make changes in specifications at any time without notice or
obligation.
