73
Two complete parameter sets are stored in the EEPROM . As
delivered, the two sets are identical but can be edited differently.
Note:
Fill in your configuration data on the following pages.
Default settings of parameter sets
*) These parameters are only edited in parameter set 1.
They are valid for both parameter sets.
Code. Parameter Default setting
o1. Sensor selection * 2200 SIE
o1. Measured variable 000.0 mS
o1. Conc solution -01-
o1. 0/4-20 mA 4-20 mA
o1. Characteristic LIN
o1. Current start (LIN) 000.0 mS
o1. Current end (LIN) 100.0 mS
o1. Current start (LOG) 0.1 mS
o1. Current end (LOG) 100 mS
o1. Filter time 0 s
o1. 22mA signal OFF
o1. HOLD response Last
o1. Fix current 021.0 mA
o2. Unit °C / °F °C
o2. 0/4 ...20mA 4-20 mA
o2. Current start 000.0 °C
o2. Current end 100.0 °C
o2. Filter time 0 s
o2. 22mA signal OFF
o2. HOLD response Last
o2. Fix current 021.0 mA
tc. Temperature compensation
OFF
tc. Temp coefficient 02.00%/K
AL. Sensocheck OFF
AL. Alarm delay 0010 sec
AL. LED Hold OFF
Code. Parameter Default setting
rL. Relay function Limit
L1. Contact function Lo
L1. Contact response N/O
L1. Setpoint 000.0 mS
L1. Hysteresis 001.0 mS
L1. Delay 0010 sec
L2. Contact function Hi
L2. Contact response N/O
L2. Setpoint 100.0 mS
L2. Hysteresis 001.0 mS
L2. Delay 0010 sec
Ct. Setpoint 050.0 mS
Ct. Neutral zone 001.0 mS
Ct. P action 0100 %
Ct. I action 0000 sec
Ct. D action 0000 sec
Ct. PLC/PFC controller PLC
Ct. Pulse length 0010 sec
Ct. Pulse frequency 0060 /min
Ct. HOLD response Last
Cn. Rinse/Pset2 * rinse
Cn. Rinsing interval * 000.0 h
Cn. Rinse duration * 0060 sec
Cn. Contact response* N/O
