21
Operation
4.6 Calibration
4.6.1 Temperature Sensor Calibration
The probe contains a temperature sensor which is factory pre-set. If there are setting
questions, the data can be validated using a high precision thermometer using
Table 1
and performing the steps in section 4.6.1.1 on page 22 .
DISP PH FORMAT (9184sc T.F.C or 9184sc Chlorine + Acid only)
Choose either XX.XX pH or XX.X pH.
pH MAXIMUM (9184sc T.F.C only)
Allows user to set the maximum pH allowed value. An higher value will display a PH TOO HIGH error message.
LOG SETUP
Allows user to select data logging interval for the sensor and temperature.
FILTER
Adjust for + s. This averages the signal over the specified time interval.
MAINS FREQ
Choose 50 or 60 Hz.
CONFIGURE (continued)
DEFAULT SETUP
Resets the sensor configuration to default settings.
DIAG/TEST
PROBE INFO
Displays the driver and software versions and the serial number.
CAL DATA
Displays OFFSET: °C, SLOPE: in A/mg and OFFSET: uA, SLOPE: %
SIGNALS
Displays INT, TEMP RAW, MV RAW and PH RAW.
COUNTERS
Displays sensor total time and humidity suppressor.
4.5 Sensor Setup Menu (continued)
