3
T
h
e d
at
a a
n
d i
n
fo
rm
at
io
n p
rovi
d
ed
i
n
t
h
is
m
an
u
al
a
re to b
e c
o
n
si
d
er
ed
s
u
sc
ep
ti
b
le to c
h
an
g
e a
t a
n
y t
im
e w
it
h
o
u
t w
ar
n
in
g
, by CAM
E c
an
ce
ll
i a
u
to
m
at
ic
i S
.p
.A
.
ENGLISH
14
CAME
CAME
CAME
CAME
:,
12
8
1
2
3
4
5
6
6
11
10
7
8
9
13
1
2 3
5
4
12
7
9
11
13
10
13
4.2 Technical information
—#
—#
4.3 Parts description
AUTOMATION UNIT
ACCESSORIES
VIEW FROM THE BAR
SUPPORT BRACKET
VIEW FROM INSPECTION
HATCH
GEARMOTOR
Power supply: 230V A.C. 50/60Hz
Motor power supply: 24V D.C. 50/60Hz
Max. absorption: 1.3A (230V) / 15A (24V)
Rated power: 300W
Max. torque: 600 Nm
Reduction ratio: 1/202 Opening time: 4÷8 s
Operative intermittence: intensive operation
Protection level: IP54
Weight: 90 kg
Insulation class: I
1) G02000/G04000 - aluminium bar, painted white, Ø 100 mm
2) G02040 - Ø40 (yellow) balancing spring
3) G04060 -Ø50 (green) balancing spring
4) G06080 - Ø55 (red) balancing spring
5) G02806 - Rack
6) G02802 - Support for DIR photoelectric cells
7) G02803 - Luminous cord
8) G02807 - Fixed barrier support
9) G02808 - Mobile barrier support
10) G02809 - Adhesive reflector strips
11) G02801 - Flashing dome lamp
12) G02805 - Emergency battery housing support
13) ZL38 - Electric board designed to accommodate radio board coupling
14) G06803 - Telescopic joint and additional insert to attach the bar
1) Upper dome
2) Bar beam plate
3) Bar fitting intermediate plate
4) Cover for aluminium bar
5) Anti-shearing protection cover
6) Sheet-steel or stainless steel cabinet with
galvanized and painted finish
7) Features for housing accessories
8) ABS container for electric
board with transformer
9) End-stop assembly
10) Lever arm
11) Transmission rod
12) Inspection hatch
13) Bar position adjustment buffers
14) Gearmotor
