Control Valve Assembly
.
Item No.
Quantity
Part No.
Description.
.
1.........................1............................1707-30............................ Valve Body, 5600 Upflow, Bayonet
.
2.........................1............................13255................................. Clip, Mounting
.
3.........................5............................13242................................. Seal, 5600
.
4.........................1............................13304................................. O-ring, -121
.
5.........................1............................12281................................. O-ring, -338
.
6.........................4............................14241................................. Spacer, 5600
.
7.........................1............................14309................................. Retainer, Piston Rod
.
8.........................1............................13030................................. Retainer, Dist Tube, O-ring
.
9.........................3............................12112.................................. Screw, Hex Hd Mach, 10-2 x 1/2
.
10.......................1............................13302................................. O-ring, -01
.
11.......................1............................1013-XX........................... Nozzle, Injector (specify size)
.
12.......................1............................101-XX........................... Throat, Injector (specify size)
.
13.......................1............................11973.................................. Spring, Brine Valve
.
14.......................1............................1181-01............................ Ring, Retaining
.
15.......................1............................12088................................. Washer, Flow 2. GPM
.
16.......................1............................12550................................. Quad Ring, -00
.
17.......................1............................12626................................. Seat, Brine Valve
.
18.......................1............................12638................................. O-ring, -013, Injector
.
19.......................1............................12977................................. O-ring, -015
.
20.......................1............................13163................................. Body, Injector
.
21.......................1............................13165................................. Cap, Brine Valve
.
22.......................1............................13167................................. Spacer, Brine Valve
.
23.......................1............................13172................................. Brine Valve Stem
.
24.......................1............................13173................................. Retainer, DLFC Button
.
25.......................1............................13244................................. Adapter, BLFC
.
26.......................1............................13245................................. Retainer, BLFC
.
27.......................2............................13301................................. O-ring, -011, Injector
.
28.......................1............................13303................................. O-ring, -021
.
29.......................1............................13497................................. Disperser, Air, 5600
.
30.......................1............................15348................................. O-ring, -563
.
31.......................1............................16098................................. Washer, Nylon Brine
.
32.......................1............................13302-01............................ O-ring, -01, 560CD
.
33.......................1............................13296................................. Screw, Hex Wsh, 6-20 x 1/2
.
34.......................2............................13314................................. Screw, Slot Ind Hex, 8-18 x .60
.
35.......................1............................13363................................. Washer, Plain, .15 ID SS
.
36.......................1............................13546................................. Retainer, End Plug
.
37.......................2............................19228................................. Coupling, Adapter
.
38.......................4............................13305................................. O-ring, -11
.
39.......................1............................14067................................. Adapter, Upflow Brine
.
40.......................1............................15449................................. Body, Regulator
.
41.......................1............................14851................................. Cap, Regulator
.
42.......................1............................17307................................. Washer, Flow, .125 gpm
.
43.......................2............................15607................................. Screw, Hex Hd Mach, 10-2 x 1 3/8
.
44.......................1............................15548................................. Screen, Pressure Regulator
.
45.......................1............................23391................................. Seat, Regulator Spring
.
46.......................1............................23393................................. Poppet, Regulator
.
47.......................1............................14850................................. Spring, Compression
.
48.......................1............................14846................................. Washer, Pressure Regulator
.
49.......................1............................14847................................. Diaphragm, Regulator
.
50.......................1............................14848................................. Ring, Slip, Regulator, SS
.
51.......................1............................24602................................. Link, Piston Rod
.
52.......................1............................15558................................. Rod, Piston, Upflow
Not Shown:
.
.
1............................12638................................. O-ring, -013, Injector
.
.
1............................12626................................. Seat, Brine Valve
.
.
1............................14613................................. Flow Straightener
.
.
1............................14846................................. Washer, Pressure Regulator
.
.
1............................14847................................. Diaphragm, Regulator
.
.
1............................14848................................. Ring, Slip, Regulator SS
.
.
1............................14850................................. Spring, Compresssion
.
.
1............................14851................................. Cap, Regulator
.
.
1............................15449................................. Body, Regulator
.
.
1............................23391................................. Seat, Regulator Spring
.
.
1............................23393................................. Poppet, Regulator
.
.
1............................15548................................. Screen, Pressure Regulator
.
.
2............................15607................................. Screw, Hex Hd Mach, 10-2 x 1 3/8
