Regeneration Cycle Step Programming
This program step programs the Regeneration Cycle step times 1 through 5. Please refer to the chart below
for regenerant flow default cycle steps and times..
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
Media Volume
This program step sets the volume of the media in the resin tank..
— Press the Shift button to select the digit you want to modify..
— Press the Up or Down buttons to adjust this value..
— Press the Extra Cycle button.
Salt Dosage
This program step sets the salt dosage in the unit..
— Press the Shift button to select the digit you want to modify..
— Press the Up or Down buttons to adjust this value..
— Press the Extra Cycle button.
Brine Line Flow Control Size
This program step allows the selection of the desired brine line flow control size in the unit (must match
physical brine line flow control)..
— Press the Up or Down buttons to adjust this value..
— Press the Extra Cycle button.
Auxiliary Relay Output
The next two displays are part of a series of settings used to program the optional relay output. The first.
setting turns the output on/off during regeneration only. The second turns the output on during service only,
every time a set volume of water used has accumulated..
NOTE: When auxiliary outputs are in the OFF (default) setting, press the Up or Down buttons to set
11.
12.
13.
14.
15.
Master Programming Mode
Regenerant Flow
Cycle 1
Time
Cycle 2
Time
Cycle 3
Time
Cycle 4
Time
Cycle 5
Time
Down Flow
Back Wash
10.
Minutes
Brine
& Slow
Rinse
1 Hour
Rapid
Rinse
10.
Minutes
Brine Tank Fill
12 Minutes
N/A
N/A
Back Wash Filter
Back Wash
15.
Minutes
Draw
0
Settling
Rinse
10.
Minutes
Refill
0
N/A
N/A
UF Back Wash
Backwash
10.
Minutes
Brine
& Slow
Rinse
1 Hour
Rapid
Rinse
10.
Minutes
Brine Tank Fill
12 Minutes
N/A
N/A
Down Flow Double
Backwash
Back Wash
10.
Minutes
Brine
& Slow
Rinse
1 Hour
Back
Wash
10.
Minutes
Rapid Rinse
10 Minutes
Brine Tank Fill
12 Minutes
Up Flow
Brine Rinse
60
Back
Wash
10
Rapid
Rinse
10.
Minutes
Brine Tank Fill
12 Minutes
N/A
N/A
Upflow Variable Fill
Brine Rinse
Variable
Pause
60.
minutes
Brine
Rinse
60.
Minutes
Back Wash
12 Minutes
Rapid Rise
10 Minutes
CAUTION: Before entering Master Programming, please contact your local professional water dealer.
