6700XTR Powerhead Assembly

Item No. Quantity

Part No.

Description

.

1...................1...................15-0...................Drive Panel Assy, 6700

.

2...................1...................17844........................Bracket, Support, 6700

.

3...................1...................13299........................Washer, Spring, 3/8

.

4...................1...................13017........................Gear, Idler

.

5...................1...................23045........................Gear, Drive, 6700

.

6...................1...................13175........................Plate, Motor Mounting

.

7...................2...................19080........................Spring, Compression, 6700

.

8...................2...................13300........................Ball, 1/” SS

.

9...................2...................13296........................Screw, Hex Wsh, 6-20 x 1/2

.

10.................1...................25005-10...................Gear, Main Drive, ET, SE

.

11.................1...................18722........................Cam, Brine Valve, 6600/6700, Blk

.

.....................1...................19025........................Cam, Brine Valve, Variable

.

12.................1...................12037........................Washer, Plain, #10

.

13.................1...................40214........................Screw, Hex Wsh, 6-20 x 3/

.

14.................2...................18754........................Pin, 6700

.

15.................1...................19079........................Washer, Friction

.

16.................1...................17885........................Cam, Brining, 6600, U/F, Red

.

.....................1...................17919........................Cam, Variable Brining, Gray

.

.....................1...................24598........................Cam, Cycle U/F, Yellow

.

17.................1...................15151........................Screw, Flat Head St, 6-20 x 3/

.

18.................2...................10218........................Switch, Micro

.

19.................1...................10302........................Insulator, Limit Switch

.

20.................2...................17876........................Screw, Phil Pan, -0 x 1 1/8

.

21.................1...................1781-XXX................Cover, Bottom, 6700

.

22.................1...................13547........................Strain Relief, Flat Cord

.

23.................1...................16944........................Motor Drive, 2V, 60 Hz, 2RPM

.

24.................3...................11384........................Screw, Phil, 6-32 x 1/

.

25.................4...................17798........................Screw, Slot Hex Hd

.

26.................2...................12473........................Screw, Hex Wsh, 10-2 x 5/8

.

27.................1...................17845........................Pin, Hinge, 6700

.

28.................1...................18679........................Cap, Tapered, Black

.

29.................1...................1782-XX..................Cover, Top 6700

.

30.................1...................18615........................Seal, Neoprene, .125

.

31.................1...................19674........................Transformer, 2V, .6VA, Residential Valves

.

.....................1...................41475........................Transformer, 2V, .6VA, European

.

32.................1...................42115........................Harness Assy, 5066/6600/6700

.

33.................1...................42274........................Timer Assy, 6700XTR
