Hydra-Flex Aqua-Lab MD Operating Manual - Manual (Page 5)

Operating Manual
© Hydra-Flex Inc 2011 - 5 -
Motor Starter (Dual Source / Dual Pump Shown)
Pump Stand (Single Pump with Back-up shown)
Current Sensor
Timer Relay
Contactor
Overload
Thermal Relief
Valve
Pressure
Regulator
Y-Strainer
Feed lines to
MD5 panels
Powerfast cord
(plugs into
bottom of
motor starter)
Back-up Pump
