SPECIFICATIONS:
The manufacturer accepts a 1/4” variance. There are variations on each tub and specifications are subject to change as we improve upon our product as required. The dimensions needed for site preparation
and structure building should be measured from the tub; Aquatic Industries, Inc. assumes no responsibility for preparatory work.
www.aquaticwhirlpools.com 800.555.5324
August 2008
Rough-In Plumbing
Measurements
mIllENNIum 9
• Available without Fast-Fill Waterfall Spout
- See Price List for details
• Jet Finish
- Chrome, Polished Brass, Gold, Polished Nickel or
Satin Nickel
• Lift & Turn Waste and Overflow
- Chrome, Polished Brass, Gold, Polished Nickel,
Satin Nickel, or
Oil Rubbed Bronze
• Cable Drive Waste and Overflow
- Chrome, Polished Brass, Gold, Polished Nickel,
Satin Nickel,
Oil Rubbed Bronze , or Color Matched
(Bone, White, and Biscuit Only)
• Hand Held Jet - Chrome or Polished Brass
• Premium Colors
All acrylic colors featured by Aquatic match the industry’s
leading fixture manufacturers.
oPtIonal equIPMent: GeneRal SPecIfIcatIonS:
Tub Size 76 1/2” diam. x 33 1/4” height
194 cm diam. x 84 cm height
Bathing Well 38 1/2” long
52” wide
25 1/4” interior depth
Shipping Weight 934 lbs. / 424 kg
Tub Weight Filled 2189 lbs. / 993 kg
Weight w/Equipment 371 lbs. / 168 kg
Gallons to Overflow 219 gal. / 829 L
Gallons to Operate 1 bather: 198 gal. / 750 L
2 bathers: 185 gal. / 700 L
electRIcal SPecIfIcatIonS:
electronic control Package:
230V; 50 AMP w/ GFCI; 4-Wire w/ dedicated Neutral
This unit is not recommended for shower installations.
This unit has a 3/4” female waterfall fill spout connection.
mIllENNIum SERIES
model # AI9mIl7700
Two Person Bath
76 1/2”
fax-on-Demand
Document # 1194
Overflow located
underneath
fill spout
15” 22”
52”
23 1/2”
Pump
Pump
Blower
no alternate pump location available.
24 Hydrotherapy Jets including:
- 12 Shiatsu-Pro Neck and Back Jets
- 2 Recessed Fan Jets
- 4 Rotary Massage Foot Jets
- 2 Rotary Massage Elite Knee Jets
- 2 Pressure Plus Wrist Jets and 2 Pressure Plus Elbow Jets
air Bath System:
- 1 HP Variable Speed Air Blower with 20-Minute Timer
- Automatic Purge and dry Cycle
- 600 Watt Air Heating System
aquatic quality features:
- Independent 2 HP, 3-Speed Run-dry Pumps
- digital Electronic Control System
- Shiatsu Electronic Control with Preprogrammed Jet Sequencer
- Waterproof Universal Remote Control
- 4 kW Inline Maintenance Heater
- 2 Pulsating Neck Jet Pillows
- Integrally Molded Fast-Fill Waterfall Spout/Optional
- please specify on order (valves not included)
- Bi-level Foot Rest
- Chromatherapy
- 2 Reclining Lounge Seats with Arm Rests
- Adjusta-Level Base
- ”Quiet Pad” Anti-Vibration Pump Mounts
- Heat-bent Rigid PVC Piping for Optimum Sanitary Conditions
- Slip Resistant Floor
- durable, Easy to Clean, Lucite® Cast Acrylic Surface
- Available in 8 Standard No-Charge Colors
ul & IaPMo listed, factory tested
limited lifetime Warranty
StanDaRD equIPMent:
33 1/4”
26”
25 3/4”
29 3/4”
3 1/4”
38 1/4”
*available without fast-fill waterfall spout.
