Hellwig Sway Bar 7643 User Manual
Installation instructions, Rear stabilizer bar
INSTALLATION INSTRUCTIONS
Rear Stabilizer Bar
Thank you for purchasing a quality Hellwig Product.
PLEASE READ THIS INSTRUCTION SHEET COMPLETELY BEFORE STARTING YOUR INSTALLATION
7643 ( R-7643 )
03/22/2013
1
2
559-734-7451 800-367-5480 FAX 559-734-7460
3
4
Jam Nut
5/8” Hourglass
Bushing
Male End Link
3/4” Hourglass
Bushing
1/2” Bushing
Sleeve
Female End
Link
7/16” Bushing
Sleeve
