500-S, 750-S, 1000-S, 1000-UP • INSTALLATION/OPERATION/SERVICE MANUAL • 33.
B O N N E T A S S E M B L Y
S E R V I C E V I E W
I T E M PA R T N O .
D E S C R I P T I O N
Q T Y
I T E M PA R T N O .
D E S C R I P T I O N
Q T Y
1
5009943
BONNET ASSEMBLY, SPOT
1
10
PE-26567
CONTROL PANEL BEZEL
1
2
BK-3019
T-BLOCK
1
11
PE-28637
CONTROL PANEL OVERLAY
1
3
BU-3964
BUSHING, STRAIN RELIEF
1
12
PG-25574
HOLE PLUG, 3/8"
1
4
CC-34488
CONTROL
2
13
PG-3589
HOLE PLUG, 13/16
1
5
CD-33824
CORDSET, 120V
1
14
SC-2190
GROUND SCREW
1
CD-3551
CORDSET, 208/240V
1
15
SC-2365
SCREW, ROUND HD, 16-32 X 1-1/4"
2
CD-3922
CORDSET, 230V
1
16
SC-2459
SCREW, PHIL, 8-32 X 1/4"
5
6
CR-34559
CONNECTOR, QUICK
4
17
SW-34769
SWITCH, ROCKER, POWER, 120V
2
7
GS-2019
GASKET
1
18
WS-22300
WASHER M4 SPLIT LOCK S/S 18-8
4
8
KN-26568
THERMOSTAT KNOB
2
19
WS-2420
WASHER, #10 NYLON
4
9
NU-22286
HEX NUT
4
20
WS-2467
WASHER, STAR LOCK
1
I T E M PA R T N O .
D E S C R I P T I O N
Q T Y
I T E M PA R T N O .
D E S C R I P T I O N
Q T Y
1
1003936
HI-LIMIT PROTECTION COVER
1
18
GS-2019
GASKET
8
2
1005836
HEAT SINK
1
19
NU-2296
NUT, HEX #8-32
4
3
5009280
BONNET ASSEMBLY, SPOT
1
20
PE-26567
CONTROL PANEL BEZEL
1
4
BA-33554
BOARD, POWER SUPPLY, 12V.DC, SWTICH
1
21
PE-27938
CONTROL PANEL OVERLAY
1
5
BK-3019
T-BLOCK
1
22
PG-25574
HOLE PLUG, 3/8"
1
6
BP-3567
BEEPER
1
23
PG-28439
PLUG, DOME, .187" HOLE
4
7
BU-3378
1-1/8" SNAP BUSHING
4
24
PG-3325
1.125" HOLE PLUG
1
8
BU-3964
BUSHING, STRAIGHT, STRAIN RELIEF
1
25
PG-3589
HOLE PLUG, 13/16
1
9
CC-34326
ELEC. CONTROL W/O TIMERS
1
26
RL-33558
RELAY, SPST 30A @ 277 VAC
2
CC-34328
ELEC. CONTROL W/ TIMERS
1
27
SC-2190
GROUND SCREW
1
10
CD-33824
CORDSET, 120V
1
28
SC-22271
SCREWS, M4-0.7X6MM PHIL
2
CD-3551
CORDSET, 208/240V
1
29
SC-2365
SCREW, ROUND HD, 16-32 X 1-1/4"
2
CD-3922
CORDSET, 230V
1
30
SC-2459
SCREW, PHIL, 8-32 X 1/4"
5
11
CL-22820
CANOE CLIP
2
31
SC-2472
SCREW, 6-32 X1/2, NC PHIL TRUSS M/S,18-8
4
12
CR-33717
CONNECTOR, 10 PIN
1
32
SC-25849
SCREW,8-32X1/2T-410PH PAN HD
6
13
CR-33718
CONNECTOR, 9 PIN
1
33
SW-34077
SWITCH, CIRCUIT BREAKER, 20 AMP
1
14
CR-33719
CONNECTOR, 8 PIN
1
34
TM-33560
TERMINAL,STRIP,5CIRCUIT,UL,VDE
2
15
CR-33761
CONNECTOR, 7 PIN
1
35
TT-33476
T-STAT, 300 F HI-LIMIT
1
16
CR-33762
CONNECTOR, 6 PIN
1
36
WS-2333
WASHER, #8 EXT LOCK
4
17
CR-3849
CONNECTOR, DUAL SPADE, 1/4"
1
37
WS-2467
WASHER, STAR LOCK
1
MANUAL CONTROL - 1000-UP
ELECTRONIC CONTROL OPTION - 1000-UP
