500-S, 750-S, 1000-S, 1000-UP • INSTALLATION/OPERATION/SERVICE MANUAL • 29.
S E R V I C E P A R T S
S E R V I C E
1000-UP
1000-UP WITH PASS THROUGH OPTION
I T E M PA R T N O .
D E S C R I P T I O N
Q T Y
I T E M PA R T N O .
D E S C R I P T I O N
Q T Y
1
13676
SHIM, HINGE
4
16
CS-24875
CASTER, SWIVEL W/ BRAKE
2
2
1006871
NON-PRODUCT PROBE SEAL*
2
17
CV-22173
COVER, HINGE
4
3
1007145
CASTER SPACER
12
18
GS-23622
GASKETS, ADHESIVE, .125X.375
1
4
1008272
BRACKET, SENSOR MTG.*
2
19
GS-23794
GASKET, DOOR
2
5
1009941
BOTTOM PANEL
1
20
HD-27080
HANDLE, OFFSET MAG. LATCH
2
6
1009942
PANEL, SIDE, STD
2
21
HG-2535
HINGE, PAIR
2
1009980
PANEL, SIDE, HD
2
22
IN-2003
INSULATION*
2
7
1009951
BONNET, TOP COVER
1
23
NU-22286
M4-0.7 HEX NUT 18-8*
2
8
1010445
FRONT TRIM
1
24
PG-25574
3/8" HOLE PLUG*
1
9
1010457
REAR TRIM, STD
1
25
PR-34494
PROBE, OVEN TEMPERATURE*
2
1010447
REAR TRIM, HD
1
26
RI-2100
RIVET, BLIND, #44, STNLS
12
10
4874
ELEMENT KIT
1
27
SC-2071
SCREW, 3/4 PAN HD
4
11
5009942
BONNET ASSEMBLY, SPOT
1
28
SC-2072
SCREW, 10-32 X 3/4, NF, PHIL, FLAT
20
5009280
BONNET ASSEMBLY, ELEC., SPOT
1
29
SC-2073
SCREW, 10-32 X 1-1/2, NF, PHIL
8
12
55646
SOLID DOOR ASSEMBLY
2
30
SC-22271
SCREWS, M4-0.7X6MM PHIL*
2
55447
DOOR ASSEMBLY W/ WINDOW
2
31
SC-2239
SCREW, 6-32 X 1/2, NC PHIL, FLAT*
4
13
BK-27878
SENSOR MOUNTING BLOCK*
2
32
SC-2332
SCREW,1/4-20 X 1/2, NC SLOT RND
4
14
BU-3378
1-1/8" SNAP BUSHING*
4
33
SC-2459
SCREW, 8-32 X 1/4 PHIL SCREW
24
15
CS-24874
CASTER, RIGID
2
34
SR-2120
SIDE RACK, CHROME
4
I T E M PA R T N O .
D E S C R I P T I O N
Q T Y
I T E M PA R T N O .
D E S C R I P T I O N
Q T Y
1
13676
SHIM, HINGE
8
16
CS-24875
CASTER, SWIVEL W/ BRAKE
2
2
1006871
NON-PRODUCT PROBE SEAL*
2
17
CV-22173
COVER, HINGE
8
3
1007145
CASTER SPACER
12
18
GS-23622
GASKETS, ADHESIVE, .125X.375
1
4
1008272
BRACKET, SENSOR MTG.*
2
19
GS-23794
GASKET, DOOR
4
5
1009941
BOTTOM PANEL
1
20
HD-27080
HANDLE, OFFSET MAG. LATCH
4
6
1009942
PANEL, SIDE, STD
2
21
HG-2535
HINGE, PAIR
4
1009980
PANEL, SIDE, HD
2
22
IN-2003
INSULATION*
2
7
1009951
BONNET, TOP COVER
1
23
NU-22286
M4-0.7 HEX NUT 18-8*
2
8
1010445
FRONT TRIM
1
24
PG-25574
3/8" HOLE PLUG*
1
9
1010551
REAR TRIM, STD
1
25
PR-34494
PROBE*
2
1010447
REAR TRIM, STD
1
26
RI-2100
RIVET, BLIND, #44, STNLS
64
10
4874
ELEMENT KIT
1
27
SC-2071
SCREW, 3/4 PAN HD, PT
8
11
5009942
BONNET ASSEMBLY, SPOT
1
28
SC-2072
SCREW, 10-32 X 3/4, NF, PHIL, FLAT
40
5009280
BONNET ASSEMBLY, ELEC., SPOT
1
29
SC-2073
SCREW, 10-32 X 1-1/2, NF, PHIL
16
12
55646
SOLID DOOR ASSEMBLY
4
30
SC-22271
SCREWS, M4-0.7X6MM PHIL*
2
55447
DOOR ASSEMBLY W/ WINDOW
4
31
SC-2239
SCREW, 6-32 X 1/2, NC PHIL, FLAT*
4
13
BK-27878
SENSOR MOUNTING BLOCK*
2
32
SC-2332
SCREW,1/4-20 X 1/2, NC SLOT RND
4
14
BU-3378
1-1/8" SNAP BUSHING*
4
33
SC-2459
SCREW, 8-32 X 1/4 PHIL SCREW
24
15
CS-24874
CASTER, RIGID
2
34
SR-2120
SIDE RACK, CHROME
4
CABLE HEATING SERVICE KIT #4874 - 500-S, 750-S, 1000-S, 1000-UP
(
ONE PER COMPARTMENT
)
PA R T N O .
D E S C R I P T I O N
Q T Y
PA R T N O .
D E S C R I P T I O N
Q T Y
CB-3044
CABLE HEATING ELEMENT
108
FT
ST-2439
STUD
4
CR-3226
RING CONNECTOR
4
NU-2215
HEX NUT
8
IN-3488
INSULATION CORNER
1
FT
SL-3063
INSULATING SLEEVE
4
BU-3105
SHOULDER BUSHING
4
TA-3540
ELECTRICAL TAPE
1
ROLL
BU-3106
CUP BUSHING
4
*
NOT SHOWN
*
NOT SHOWN
