500-S, 750-S, 1000-S, 1000-UP • INSTALLATION/OPERATION/SERVICE MANUAL • 31.
B O N N E T A S S E M B L Y
S E R V I C E
I T E M PA R T N O .
D E S C R I P T I O N
Q T Y
I T E M PA R T N O .
D E S C R I P T I O N
Q T Y
1
5009353
BONNET, SPOT, 500-S
1
PE-26566
CONTROL PANEL BEZEL, 750-S
1
5009347
BONNET, SPOT, 750-S
1
PE-26567
CONTROL PANEL BEZEL, 1000-S
1
5009114
BONNET, SPOT, 1000-S
1
11
PE-28700
CONTROL PANEL OVERLAY, 500-S
1
2
BK-3019
T-BLOCK
1
PE-28701
CONTROL PANEL OVERLAY, 750-S
1
3
BU-3964
BUSHING, STRAIN RELIEF
1
PE-28638
CONTROL PANEL OVERLAY, 1000-S
1
4
CC-34488
CONTROL
1
12
PG-25574
HOLE PLUG, 3/8"
1
5
CD-3232
CORDSET, 120V
1
13
PG-3589
HOLE PLUG, 13/16
2
CD-3551
CORDSET, 208/240V
1
14
SC-2190
GROUND SCREW
1
CD-3922
CORDSET, 230V
1
15
SC-2365
SCREW, ROUND HD, 16-32 X 1-1/4"
2
6
CR-34559
CONNECTOR
4
16
SC-2459
SCREW, PHIL, 8-32 X 1/4"
5
7
GS-2019
GASKET
1
17
SW-34769
SWITCH, ROCKER, POWER
1
8
KN-26568
THERMOSTAT KNOB
1
18
WS-22300
WASHER M4 SPLIT LOCK S/S 18-8
2
9
NU-22286
HEX NUT
2
19
WS-2420
WASHER, #10 NYLON
2
10
PE-26565
CONTROL PANEL BEZEL, 500-S
1
20
WS-2467
WASHER, STAR LOCK
1
MANUAL CONTROL - 500-S, 750-S, 1000-S
ELECTRONIC CONTROL - 500-S, 750-S, 1000-S
I T E M PA R T N O .
D E S C R I P T I O N
Q T Y
I T E M PA R T N O .
D E S C R I P T I O N
Q T Y
1
1003936
HI-LIMIT PROTECTION COVER
1
PE-26567
PANEL CONTROL BEZEL, 1000-S
1
2
1005836
HEAT SINK
1
19
PE-27934
OVERLAY, ELEC, 500-S
1
3
5006075
BONNET SPOT ASSBY, 500-S
1
PE-27267
OVERLAY, ELEC, 750-S
1
5004770
BONNET SPOT ASSBY, 750-S
1
PE-27082
OVERLAY, ELEC, 1000-S
1
5005031
BONNET SPOT ASSBY, 1000-S
1
20
PG-25574
3/8" HOLE , 120V ONLY
1
4
5007164
HI-LIMIT BULB COVER, SPOT
1
21
PG-28439
PLUG, DOME,.187" HOLE, 500-S, 750-S
4
5
BA-33554
POWER SUPPLY
1
22
PG-3559
7/8" HOLE PLUG, 500-S, 750-S
1
6
BK-3019
T-BLOCK
1
PG-3325
1.125" HOLE PLUG, 1000-S ONLY
1
7
BP-3567
BEEPER
1
23
PG-3589
PLUG, HOLE,13/16
1
8
BU-3008
3/4" WHITE SNAP BUSHING, 500-S
1
24
RL-33558
RELAY, SPST 30A @ 277 VAC 12VDC
1
BU-3378
1-1/8" SNAP BUSHING, 750-S
1
25
SC-2190
10-32 X 1/4 PAN HD GROUND SCREW
1
9
BU-3964
BUSHING,STRAIGHT,STRAIN RELIEF
4
26
SC-22271
SCREWS,M4-0.7X6MM PHIL
2
10
CC-34322
ELECTRONIC CONTROL W/O TIMERS
1
27
SC-22500
SCREW 6-32 X 1/4" PAN HD
2
CC-34324
ELECTRONIC CONTROL W/ TIMERS
1
28
SC-2365
SCREW,6-32X1-1/4,NC PHILLIPS
2
11
CD-3922
CORDSET, 16AWG, 3C, 230V
1
29
SC-2459
8-32 X 1/4" PHIL SCREW
5
CD-3232
CORDSET, 14/3 SJTOW, 120V
1
30
SC-2472
SCREW,6-32 X1/2,NC PHIL TRUSS
2
12
CL-22820
CANOE CLIP
1
31
SC-25849
SCREW,8-32X1/2T-410PH PAN HD
2
13
CR-33718
CONNECTOR 9 PIN
2
32
SW-34077
SWITCH, CIRCUIT BREAKER, 20 A
1
14
CR-33761
CONNECTOR, 7 PIN
1
33
TA-25621
TAPE
1
15
CR-33763
CONNECTOR 4 PIN
1
34
TM-33560
TERMINAL,STRIP,5CIRCUIT,UL,VDE
1
16
GS-2019
GASKET, 102"
1
35
TT-33476
T-STAT, 300 F HI-LIMIT
1
17
NU-2296
NUT, HEX #8-32
1
36
WS-2333
WASHER, #8 EXT LOCK
4
18
PE-26565
PANEL CONTROL BEZEL, 500-S
1
37
WS-2467
STAR LOCK WASHER
1
PE-26566
PANEL CONTROL BEZEL, 750-S
1
