CIRCUIT DESCRIPTION :
The circuit uses a step down tranformer to provide step down
supply to a single phase variable autotransformer to obtain an
output voltage variable from 0 to 130VAC. This is followed by a
triple shielded isolation transformer which provides an output
voltage from 0-130VAC or 0-260VAC electrostatic and galvanic
isolation.
Multiple shielding technique reduces primary to secondary static
coupling to below 0.0005pF. The DC isolation is over 1000 M
Ohms.
4
SECTION - 7
PART LIST
PCB Components GLOBAL 1505 / 06 SW - 0396
=======================================================================
Reference Designator Part Description
=======================================================================
RESISTORS
R1
1.5K, ¼W ±5% MFR
R2 120E, ¼W ±5% MFR
R3 10K, ¼W ±5% MFR
R4 62K, ¼W ±5% MFR
R5 10 ohm, ¼W ±5% MFR
R6 220 ohm, ¼W ±5% MFR
R7 Not Used
R8 10K, ¼W ±5% MFR
R9 100K, ¼W ±5% MFR
R10 10M, ¼W ±5% MFR
R11 4.7K, ¼W ±5% MFR
R12 10K, ¼W ±5% MFR
R13 1.2M, ¼W ±5% MFR
R15 470K, ¼W ±5% MFR
CAPACITORS
C1
1µf, 50V ±20%, ELEC
C2 1µf, 50V ±20%, ELEC
C3 220µf, 16V ±20%, ELEC
C4 220µf, 50V ±20%, ELEC
C5 0.1µf, 100V ±10%, MP
C6 0.22µf, 100V ±10%, MP
PRESETS
PR1
100E Horizontal
PR2 100E Horizontal
PR3 100E Horizontal
PR4 10K Horizontal
DIODES
CR1
1N4007
CR2 1N4148
CR1 1N4148
