Global Specialties 1506 User Manual
Page 4
SECTION - 2
SPECIFICATIONS
INPUT VOLTAGE
: 230V AC
INPUT FREQUENCY
: 47 to 63 Hz.
OUTPUT
: I : 0 to 130 VAC at 4AMP Max.
( Available on American
socket only. )
II : 0 to 260 VAC at 2AMP Max.
( Available on European
socket only. )
METERING
: 3 digit DPM to read
1) Output Voltage.
2) Load Current and
3) Leakage current
upto 9.99 mA.
METER ACCURACY
: ± 3 counts.
OUTPUT-LINE ISOLATION : Capacitive coupling
less than 0.0005 pF.
NOISE REJECTION
: Better than 120 db
( common mode noise ).
DIMENSIONS (W x H x D )
: 11.73" x 5.23" x 10.62"
WEIGHT
: 35 lb. approx.
2
PCB Components
0893 DPM
=======================================================================
Reference Designator
Part Description
========================================================================
CAPACITORS
C1
220pf 100V ±20% CD
C2
0.1µf 100V ±10% MP
C3
0.01µf 100V ±20% CD
C4
0.47µf, 100V ±20% CD
C5
0.1µf, 50V ±10% MP
C6
10µf, 35V ±20% EL
C7
0.1µf, 50V ±10% MP
C8
0.1µf, 50V ±20% CD
C9
Not used
C10
470µf, 35V ±20% EL
C11
2.2µf, 50V ±20% EL
* C12
47µf 50V, ±20% EL ( Additional )
* C13
0.1µf 50V, ±20% CD ( Additional )
DIODES
D1
1N4148
D2
1N4148
D3 TO D6
1N4007
TRANSISTORS/FET’S
Q1
TL431
Q2
MPSA12
Q3
LM7805
IC
IC1
ICL 7107 CPL
FND’S
DS1
TSD566 ( Green )
DS2
TSD566 ( Green )
DS3
TSD566 ( Green )
LED’S
LED1
3mm GREEN Defused
LED2
3mm GREEN Defused
CONNECTORS
CON1
3 PIN 2.54 PITCH ( Male / Female )
CON2 ( L' Type ) 7 PIN 2.54 PITCH ( Male / Female )
