5-4
Installation and Operation Manual
X-VA-MT 3750C-eng
Part Number: 541B063AAG
April, 2014
Brooks ® Ar-Mite TM MT3750C
Section 5 Parts List
QTY. Description
1 Scale Model MT3750
1 Indicator Cover MT3750
1 KFA relay Ex 1W, 220V/50Hz Intrinsically safe
1 KFA relay Ex 2W, 220V/50Hz Intrinsically safe
1 KFA relay Ex 1W, 110V/60Hz Intrinsically safe
1 KFA relay Ex 2W, 110V/60Hz Intrinsically safe
1 KFD 2 CR Ex 1.20 200, 24 Vdc Intrinsically safe
1 KFA 6-STR-1.24.500 *
1 Pointer assy standard indicator
1 Pointer assy for alarm
1 Sleeve Initiator
1 Indicator Cover Gasket
4 Indicator Cover Mounting screws
1 Alarm, Transmitter Cover O-ring
1 Transmitter assembly
1 Alarm, Transmitter Fixation screw
1 Reed Switch Alarm assembly
Table 5-2 Model MT 3750 Indicator, Alarm and Transmitter Spare Parts List
* Note:
Power Supply Unit 110/220 AC input to 24 Vdc output to feed KFD 2 CR Ex 1.20 200
