Page 41
5-3
Installation and Operation Manual
X-VA-MT 3750C-eng
Part Number: 541B063AAG
April, 2014
Brooks
®
Ar-Mite
TM
MT3750C
Section 5 Parts List
POS. QTY.
Description
4
2
O-ring size 015 Viton
4
2
O-ring size 015 Buna
4
2
O-ring size 015 EPDM
4
2
O-ring size 015 Teflon
5
1
Cartridge valve low flow, Viton O-rings
5
1
Cartridge valve medium flow, Viton O-rings
5
1
Cartridge valve high flow, Viton O-rings
5
1
Cartridge valve low flow, Buna O-rings
5
1
Cartridge valve medium flow, Buna O-rings
5
1
Cartridge valve high flow, Buna O-rings
5
1
Cartridge valve low flow, EPR O-rings
5
1
Cartridge valve medium flow EPR O-rings
5
1
Cartridge valve high flow EPR O-rings
5
1
Cartridge valve low flow Telfon/Kalrez O-rings
5
1
Cartridge valve medium flow Teflon/Kalrez O-rings
5
1
Cartridge valve high flow Teflon/Kalrez O-rings
6
1
NRS #3 valve, Viton O-rings
6
1
NRS #4 valve, Viton O-rings
6
1
NRS #5 valve, Viton O-rings
6
1
NRS #6 valve, Viton O-rings
6
1
NRS #7 valve, Viton O-rings
6
1
NRS #3 valve, Buna O-rings
6
1
NRS #4 valve, Buna O-rings
6
1
NRS #5 valve, Buna O-rings
6
1
NRS #6 valve, Buna O-rings
6
1
NRS #7 valve, Buna O-rings
6
1
NRS #3 valve, EPR O-rings
6
1
NRS #4 valve, EPR O-rings
6
1
NRS #5 valve, EPR O-rings
6
1
NRS #6 valve, EPR O-rings
6
1
NRS #7 valve, EPR O-rings
6
1
NRS #3 valve, Teflon/Kalrez O-rings
6
1
NRS #4 valve, Teflon/Kalrez O-rings
6
1
NRS #5 valve, Teflon/Kalrez O-rings
6
1
NRS #6 valve, Teflon/Kalrez O-rings
6
1
NRS #7 valve, Teflon/Kalrez O-rings
7
1
Inlet O-rings seal plug
8
1
Lock pin for valve/plug
9
1
Float assy Model MT 3750; #0
9
1
Float assy Model MT 3750; #1 thru 6
10
1
Outlet float stop spring
11
1
Outlet O-ring seal plug
Table 5-1 Model MT 3750 Recommended Spare Parts List (Refer to Figure 5-1)
