25
SKX-F SERIES PARTS LIST
Pump Model SKX08CSSF SKX15CSSF SKX22CSSF SKX37CSSF SKX55CSSF SKX75CSSF SKX110CSSF SKX150CSSF
Pos. No. Part Description Item # Item # Item # Item # Item # Item # Item # Item #
01-2 Stand Only 201988 201995 201989 201994 201999 201999 202001 202001
02 Suction Cover - - - - 202881 202881 221X 221X
03 Impeller Nut 202894 202894 202894 202894 202897 202897 202897 202897
04 Impeller Washer 202907 202907 202907 202907 202917 202917 202917 202917
05 Impeller 202958 202962 202965 202968 202137 202139 202946 202948
06 Impeller Key 202140 202140 202140 202140 202146 202146 202146 202987
07 Pump Housing 202176 202172 202177 202181 202190 202190 202194 202194
07-1 O-Ring (Kit Only) Kit Kit Kit Kit - - - -
08 Oil Chamber Cover 202214 202214 202219 202219 202222 202222 202224 202224
08-1 O-Ring (Kit Only) Kit Kit Kit Kit Kit Kit Kit Kit
09 Lip Seal FKM 202232 202232 202235 202235 202243 202243 202243 202243
13 Mechanical Seal FKM** 200500 200500 200301 200301 200307 200307 200307 200307
13-2 Mechanical Seal Retainer - - - - 202273 202273 202273 202273
14 Lower Ball Bearing (*=qty 2 Needed) 200958 200958 200959 200959 200962 200962 200962* 200962*
14-2 Lower Bearing Retainer 202279 202279 202279 202279 203075 203075 203076 203076
14-3 Lock Nut & Lock Washer 200424 200424
17 Rotor w/ Shaft, 3PH 204021 204022 204023 204024 204027 204028 204029 204030
18 Stator w/ Casing 208V, 3PH 200527 200531 200535 200539 200672 - - -
18 Stator w/ Casing 230/460V,3PH 200549 200553 200557 200561 200575 200579 200583 -
18 Stator w/ Casing 460V,3PH - - - - - - - 200587
18 Stator w/ Casing 575V, 3PH 200591 200595 200599 200603 200619 200625 200632 200639
19 Wire Connection Kit* 204202 204202 204203 204203 204203 204203 CTF CTF
20 Upper Ball Bearing 200967 200967 200958 200958 200968 200968 200968 200968
20-1 O-Ring (Kit Only) - - - - Kit Kit Kit Kit
21A Oil Chamber/Motor Housing 202197 202197 202198 202198 202200 202200 202201 202201
21A-1 O-Ring (Kit Only) Kit Kit Kit Kit Kit Kit Kit Kit
26 Pump Top Cover (w/ Sensor opening) 202436 202436 202438 202438 203130 203130 202443 202444
26-1 O-Ring (Kit Only) Kit Kit Kit Kit Kit Kit Kit Kit
27 Power Cable w/ Gland- 3PH(high temp) 201733 201733 203777 203777 203777 203777 203779 203779
27-1 O-Ring (Kit Only) Kit Kit Kit Kit Kit Kit Kit Kit
27-2 Seal Minder/Temp. Sensor Cord (High Temp) 201741 201741 201741 201741 201741 201741 201741 201741
27-2-1 O-Ring Kit Only Kit Kit Kit Kit Kit Kit Kit Kit
31D Seal Minder Sensor w/ wire 202408 202408 203999 203999 204001 204001 204001 204001
31E Ground Wire w/Ring Term. 203145 203145 203145 203145 203145 203145 203145 203145
32 Power Cord Line Clip / Strain Relief 203161 203161 202499 202499 202499 202499 202500 202500
