19
J-F SERIES PARTS LIST
Pump Model J400F J750F J1500F J1500HF
Pos. No. Part Description Item # Item # Item # Item #
01 Strainer with Bottom Plate 201964 - - -
01 Strainer - 201969 201969 201969
01-2 Bottom Plate - 202007 202007 202007
02 Suction Cover - 202026 202026 202026
05 Impeller 202055 202930 202062 202064
07 Pump Housing 202993 202163 202165 202163
07 -1 O-Ring (Kit Only) Kit Kit Kit Kit
08 Oil Chamber Cover 202207 202211 202211 202211
08 -1 O-Ring (Kit Only) Kit Kit Kit Kit
09 Lip Seal FKM 202230 202233 202233 202233
10 Shaft Sleeve 202258 - - -
13 Mechanical Seal FKM** 202260 200500 200500 200500
14 Lower Ball Bearing 200957 200958 200958 200958
17 Rotor w/ Shaft 115/230V, 1PH 202302 204060 204109 204109
18 Stator w/Casing,115V, 1PH (High-Temp) 201032 201036 - -
18 Stator w/Casing, 230V, 1PH (High-Temp) 201033 201037 201040 201040
19 Wire Connection Kit* 204204 204211 204211 204211
20 Upper Ball Bearing 200957 200967 200967 200967
21A Oil Chamber 202796 - - -
21A-1 O-Ring (Kit Only) Kit - - -
21B Motor Cover 202365 202368 202368 202368
22 Cover Plate Upper 202380 - - -
26 Pump Top Cover 203120 202433 202433 202433
26-1 O-Ring (Kit Only) Kit Kit Kit Kit
27 Power Cable w/ Gland-115V, 1PH (High-Temp) 202785 202783 - -
27 Power Cable w/ Gland-230V, 1PH (High-Temp) 202785 202784 202783 202783
27-1 O-Ring (Kit Only) Kit Kit Kit Kit
27-2 Sensor Cable (High-Temp) - 201743 201743 201743
27-2-1 O-Ring (Kit Only) - Kit Kit Kit
31D Oil Sensor w/Wire 202409 202409 202409 202409
31E Ground Wire w/Ring Term. 203145 203145 203145 203145
32 Power Cord Line Clip / Strain Relief 203161 203161 203161 203161
33 Sensor Cord Line Clip - 203163 203163 203163
34 Handle 202517 202517 202517 202517
35 Holding Rods 202665 202666 202668 202668
38 Discharge Nipple 202531 202531 202534 202531
50-01 Bolt - Strainer/Stand 202694 203238 203238 203238
50-02 Screw - 203216 203216 203216
50-07 Bolt - Suction Cover 203216 - - -
50-08 Screw 203215 203219 203219 203219
50-11 Screw 203218 203218 203218 203218
50-11-1 O-Ring (Kit Only) Kit Kit Kit Kit
50-12 Screw 203218 203218 203218 203218
50-12-1 O-Ring (Kit Only) Kit Kit Kit Kit
50-22 Screw 202692 - - -
50-27 Screw 203216 203216 203216 203216
50-27-2 Screw - 203216 203216 203216
50-31E Screw 202692 202692 202692 202692
50-32 Screw 203214 203214 203214 203214
50-33 Screw - 203214 203214 203214
50-34 Screw 203219 203219 203219 203219
202626 202631 202631 202631 O-Ring Kit-FKM
* "F" Series High Temperature Pumps Only
