KB SERIES PARTS LIST
Pump Model KB55 KB55H KB75 KB75H KB110 KB110H
Pos. No. Part Description Item # Item # Item # Item # Item # Item #
01 Strainer / Stand 202013 202013 202014 202013 202014 202014
02 Wear Plate 202863 202015 202865 202866 202024 202025
02W Suction Cover 202878 202878 202879 202878 202879 202879
04 Lock Washer 202904 202904 202904 202904 202904 202904
05 Impeller 202924 202925 202926 202927 202928 202929
05W Agitator 202058 202058 202058 202058 202058 202058
06 Impeller Key 202145 202145 202145 202145 202145 202145
07 Pump Housing 203036 203036 203033 203036 203033 203033
07-3 Pump Housing Sleeve 202182 202182 202182 202182 202182 202182
08 Oil Chamber Cover 202228 202228 202228 202228 202228 202228
08 -1 O-Ring (Kit Only) Kit Kit Kit Kit Kit Kit
09 Lip Seal Buna N 202248 202248 202248 202248 202248 202248
10 Shaft Sleeve 203074 203074 203074 203074 203074 203074
13 Mech. Seals - Set Buna N (Optional) 201016 201016 201016 201016 201016 201016
13 Mech. Seals - Set FKM 201015 201015 201015 201015 201015 201015
13-2 Mech. Seal Retainer 202274 202274 202274 202274 202274 202274
14 Lower Ball Bearing 200963 200963 200963 200963 200962 200962
14-2 Lower Bearing Retainer 202276 202276 202276 202276 202282 202282
16 Motor Housing 203078 203078 203079 203079 203080 203080
17 Rotor w/ Shaft, 3 phase 202355 202355 202356 202358 202357 202357
18 Stator 230V/460V, 3 phase, 60Hz 200674 200674 200677 200705 200679 200679
18 Stator 575V, 3 phase, 60 Hz 200676 200676 200678 200706 200680 200680
20 Upper Ball Bearing 200968 200968 200968 200968 200968 200968
20-1 O-Ring (Kit Only) Kit Kit Kit Kit Kit Kit
20-2 Spring Washer 202361 202361 202361 202361 202361 202361
21A Lower Bearing Housing 202376 202376 202376 202376 202375 202375
21A-1 O-Ring (Kit Only) Kit Kit Kit Kit Kit Kit
23 Overload 230V, 3PH 202394 202394 202396 202396 202397 202397
23 Overload 460V, 3PH 202393 202393 202394 202394 202398 202398
23 Overload 575V, 3 PH 202391 202391 202393 202393 202394 202394
