Operation Key and Screen Display Information
Operation Button
(No. of pushing times)
First Digit No. Output resolution
2 1 OUT_1024x768
3 2 OUT_1280x720p_60Hz
4 3 OUT_1920x1080_30Hz
Initial Status 4 OUT_1920x1080_60Hz, (default)
1 5 OUT_1920x1080_60Hz_RB
(NOTE)
Operation button: When operation button is pressed, output resolution is changed. Please note that the number shown in the
operation button is the time that users need to press the button.
Second Digit No. Input resolution
- No input detected
1 IN_1280x720p (max. 60 frames)
2 IN_1920x1080i(50 or 60 field)
3 IN_1920x1080p(30 frame only, doesn’t support 60 frame)
(NOTE)
Input resolution depends on the input signal
(NOTE)
Please note that this device has the same function as HD-SDI repeater that extends the signal transmission distance up to
150m.
