Composition of the NF CESI DIETRISOL DUO solar systems packages (for France only)
Check the composition of the CESI solar system, which complies
with the requirements of the NF CESI mark, using the table below.
The references and packages listed must be shown on the invoice for
the system sold by the installer.
A system is complete and functional according to the NF CESI mark
if all system references appear on the invoice.
The system is composed of the following elements:
• A collector field with 1, 2 or 3 solar collectors.
• A solar domestic hot water tank to which a solar station
incorporating a heating pump, an expansion vessel and a
Diemasol A control system is to be mounted.
• The solar fluid that protects the installation from frost and
corrosion.
The system is delivered to the installer in two units: a roof pack
containing the collectors, their mounting system and the hydraulic
connections on the one hand, and a cellar pack containing the
calorifier, the system components and the solar fluid on the other
hand..
INISOL DUO/2
400-4
2
On roof
ER 154
100014076
BSP 400 E
EC 336
100006754
400
Boiler
EG 101
89807794
2
Roof-integral
Installation
(> 20°)
ER 155
100014077
2
Roof-integral
Installation
(17°)
ER 231
100014741
INISOL DUO/2
400-6
3
On roof
ER 156
100014078
BSP 400 E
EC 336
100006754
400
Boiler
EG 101
89807794
3
Roof-integral
Installation
(> 20°)
ER 157
100014079
3
Roof-integral
Installation
(17°)
ER 232
100014742
CESI System
Array of collectors
Domestic hot water production
Solar fluid
Number of
panels
Type of mounting
package /
Reference
DHW calorifier type
package /
Reference
Volume
(litres)
Back-up type
package /
Reference
CESI System
Array of collectors
Domestic hot water production
Solar fluid
Number of
panels
Type of mounting
package /
Reference
DHW calorifier type
package /
Reference
Volume
(litres)
Back-up type
package /
Reference
DIETRISOL DUO
E 300-4
2
On roof
(mechanical tiles -
Universal hook)
ER 432
100019695
BESC 300 E
EC 332
100006750
300
Electric
EG 100
89807792
2
On roof
(Slates)
ER 433
100019696
2
On roof
(mechanical tiles -
On rafter)
ER 434
100019697
2
Roof-integral
Installation
(> 20°)
(mechanical tiles)
ER 442
100019705
2
Roof-integral
Installation
(> 20°)
(Slates / Flat tile)
ER 446
100019709
