OPENER
HARDWARE
BAG
STEPLADDER
TAPE MEASURE
WOOD
BLOCK
HAMMER
HACKSAW
1/2” OPEN END
WRENCH
SOCKET WRENCH
3/8” SOCKET
7/16” SOCKET
LEVEL
DRILL
DRILL & BITS
SCREW DRIVER
SMALL SCREW DRIVER
(1/8” HEAD)
SAFE FINISH HARDWARE
COMPONENT IDENTIFICATION
TOOLS REQUIRED
WALL PUSHBUTTON
!!!!
Child can be pinned under automatic garage
door. Death or serious injury can result.
• Never let child walk or run under moving door.
• Never let child use door opener controls.
• Always keep moving door in sight.
• If person is pinned, push control button or use
emergency release.
• Test door opener monthly:
Refer to your owner’s manual Place one-inch object (or 2x4 laid flat) on floor. If door fails to reverse on contact, adjust opener. If opener still fails to reverse door, repair or replace opener.
WAR NI NG
PUSHBUTTON
“WARNING” LABEL
SAFE FINISH
SENSOR ‘U’
BRACKET
PHOTOSYSTEM
SENSORS
SENSOR ‘L’
BRACKET
DOOR ARM
TUBE SECTION
DOOR ARM ROD
WALL
BRACKET
TRANSMITTER
OPTIONAL
POWER HEAD/DRIVE
RAIL ASSEMBLY
DOOR
BRACKET
MANUAL RELEASE
TAG
BELL WIRE
SPOOL
(when supplied)
RED
RELEASE
KNOB
