Rev. 10/08
- 15 - D902/3
6. Route the transducer cable back to the transmitter
mounting area avoiding high voltage cable trays and
conduits. Do not attempt to add additional cable to the
factory supplied transducer cable. The D902/3
processes very small signals, so the cable shield must
be continuous.
7. If the transducers are to be permanently mounted using
Dow 732, the RTV must be completely cured before
proceeding to Instrument Startup. Ensure that no
relative motion between the transducer and pipe occurs
during the 24 hour curing process. If Dow 111 grease
was used for temporary operation of the D902/3
system, proceed with the Instrument Startup procedures.
Transducer Installation is complete.
PART 2 - TRANSDUCER INSTALLATION
