Alto-Shaam Cook - Manual (Page 26)

simple control smokers
•
installation
/
operation
/
service manual
-
pg
. 24
CABLE HEATING KIT #4881 - 208-240V, 230V
( one per compartment )
DESCRIPTION PART NO. QTY DESCRIPTION PART NO. QTY
CABLE HEATING ELEMENT CB-3045 210 FT STUD ST-2439 12
RING CONNECTOR CR-3226 12 HEX NUT NU-2215 24
INSULATION CORNER IN-3488 1 FT INSULATING SLEEVE SL-3063 12
SHOULDER BUSHING BU-3105 12 ELECTRICAL TAPE TA-3540 1 ROLL
CUP BUSHING BU-3106 12
S E R V I C E
CABLE HEATING KIT #4878 - 120V
(
one per compartment
)
DESCRIPTION PART NO. QTY DESCRIPTION PART NO. QTY
CABLE HEATING ELEMENT CB-3045 112 FT STUD ST-2439 6
RING CONNECTOR CR-3226 6 HEX NUT NU-2215 12
INSULATION CORNER IN-3488 1 FT INSULATING SLEEVE SL-3063 6
SHOULDER BUSHING BU-3105 6 ELECTRICAL TAPE TA-3540 1 ROLL
CUP BUSHING BU-3106 6
D A N G E R
DISCONNECT UNIT FROM
POWER SOURCE BEFORE
CLEANING OR SERVICING.
D A N G E R
LOCK-OUT OR POST
BREAKER PANEL UNTIL
SERVICE WORK HAS
BEEN COMPLETED.
