Alto-Shaam Cook - Manual (Page 21)

simple control smokers
•
installation
/
operation
/
service manual
-
pg
. 19
MODEL > 767-SK 1000-SK/II
ITEM DESCRIPTION PART NO. QTY PART NO. QTY
1 CHIP TRAY WELD 4652 1 4652 1
2 SHIM, HANDLE 13947 1 13947 1
3 DRIP PAN WELD 14831 1 5005616 1
4 NON-PRODUCT PROBE SEAL 1006871 1 1005886 1
5 CASTER SPACER 1007145 12 1007145 12
6 BRACKET, SENSOR MTG . 1008272 1 1008272 1
7 BACK CASING 1010393 1 1011878 1
8 BOTTOM PANEL 1010394 1 1009941 1
9 SIDE PANEL 1010395 2 1010575 2
10 ELEMENT COVER 1010409 1 1011813 1
11 BONNET TOP COVER 1011671 1 1011668 1
12 SMOKE HEATER PLATE WELD 5003782 1 5003782 1
13 CABLE INSULATION 5009884 1 5012753 1
14 DRIP TRAY KIT 5010391 1 5009716 1
15 DOOR ASSEMBLY 5010946 1 5013150 1
16 BONNET ASSEMBLY 5012412 1 5012758 1
17 BLOCK, SENSOR BK-27878 1 BK-27878 1
18 BLOCK, TERMINAL, PORCELAIN BK-33546 1 BK-33546 1
19 BRACKET, CHIP TRAY BT-29217 1 BT-29217 1
20 5/8” SNAP BUSHING, BLACK BU-3611 2 BU-3611 2
21 CASTER, 1 .5" STEM, RIGID 5” WHL CS-24874 2 CS-24874 2
22 CASTER, 1 .5" STEM, 5" SWIV WHL, w/BRK- CS-24875 2 CS-24875 2
23 GASKETS, ADHESIVE, .125X .375 [lin ft] GS-23622 8 GS-23622 1
24 HANDLE, OFFSET MAG LATCH HD-27080 1 HD-27080 1
25 HINGE, 1-3/8" OFFSET, PAIR, CHROME HG-22338 1 HG-22338 2
26 NUT, 1/4-20 HEX S/S NU-2437 2 NU-2437 2
27 PROBE PR-34494 1 PR-34494 1
28 SCREW, 10-32 X 3/4 PHILLIPS PAN HD SC-2071 2 SC-2071 2
29 SCREW, 10-32 X 3/4, NF PHIL, FLAT M/S, 18-8 S/S SC-2072 6 SC-2072 6
30 SCREW, 10-32X1-1/2, NF, PHIL,FLAT M/S,18-8 S/S SC-2073 10 SC-2073 6
31 SCREW, 6-32 X 1/2, NC PHIL, FLAT SC-2239 2 SC-2239 2
32 SCREW, 1/4-20 X 1/2, NC SLOT RND SC-2332 4 SC-2332 4
33 SCREW, 8-32 x 1/4" PHIL SC-2459 33 SC-2459 31
34 SHELF, WIRE S/S SH-2324 2 SH-2325 3
35 SHELF, RIB RACK SH-2743 1 SH-29474 1
36 SIDE RACK SR-28405 2 SR-2266 2
EXTERIOR PARTS LIST -
single compartment
S E R V I C E
D A N G E R
DISCONNECT UNIT FROM
POWER SOURCE BEFORE
CLEANING OR SERVICING.
D A N G E R
LOCK-OUT OR POST
BREAKER PANEL UNTIL
SERVICE WORK HAS
BEEN COMPLETED.
