Exterior parts list, Bonnet assembly, Mid-bonnet assembly – Alto-Shaam Cook User Manual
Page 25
simple
control
smokers
•
installation
/
operation
/
service
manual
-
pg
. 23
EXTERIOR PARTS LIST -
electronic
components
S E R V I C E
ITEM
DESCRIPTION
PART NO. QTY ITEM
DESCRIPTION
PART NO. QTY
1
SWITCH COVER
11133
1
22
WHITE PILOT LIGHT, 208-240V, 230V
LI-3951
1
2
BRACKET, PILOT LIGHT MTG
1004360
1
WHITE PILOT LIGHT, 120V
LI-3027
1
3
ACCESS COVER
1009990
1
23
NUT, 10-32, NF HEX MS, #18-8 S/S
NU-2215
4
4
FAN TUNNEL COVER
1011565
1
24
M4-0 .7 HEX NUT 18-8
NU-22286
4
5
BONNET SPOT ASSEMBLY
5008982
1
25*
NUT, HEX #8-32
NU-2296
2
6
T-BLOCK
BK-3019
1
26
CONTROL PANEL OVERLAY - 1000
PE-29383
1
7
BRACKET, TETHER
BT-26884
1
CONTROL PANEL OVERLAY - 767, 1767
PE-29361
1
8
1/2" HOLE BUSHING
BU-3006
1
27
PLUG, 3/8 HOLE
PG-25574
2
9
7/8" SNAP BUSHING
BU-3007
1
28
PLUG, 13/16 HOLE
PG-3589
2
10
1 1/8" SNAP BUSHING
BU-3378
8
29
10-32 X 1/4 PAN HD GROUND SCREW
SC-2190
1
11
CABLE, WIRE HARNESS
CB-34945
1
30
SCREWS, M4-0 .7X6MM PHIL
SC-22271
2
12
CONTROL
CC-34488
1
31
8-32 X 2 SLOT PAN HEAD 18-8 S .S .
SC-23154
2
13*
CORDSET, 230V
CD-3922
1
32
6-32 X 1-1/4" ROUND HD
SC-2365
2
CORDSET, 120V
CD-3397
1
33
SCREW, 10-32 X 1/2", NF PHIL, FLAT
SC-23670
4
14
CONNECTOR
CR-35022
2
34*
8-32 X 1/2" PHIL SCR EW
SC-2425
2
15*
CONNECTOR, QUICK DISCONNECT
CR-34638
2
35
8-32 X 1/4" PHIL SCREW
SC-2459
7
16
CONNECTOR-5 CONDUCTOR
CR-34646
2
36
SWITCH, RKR, 20AMP, 250V, GREEN
SW-34769
1
17
CONNECTOR, FERRULE #18
CR-34827
4
37
SWITCH, VOLTAGE, 208-240V, 230V
SW-3528
1
18
ELEMENT, SMOKER, 208-240V, 230V
EL-35022
2
38
TIMER, 208-240V, 230V
TR-34539
1
ELEMENT, SMOKER, 120V
EL-35023
2
TIMER, 120V
TR-34540
19
FAN, 3" BOX, 208-240V, 230V
FA-34524
1
39
THERMOSTAT, COOK
TT-34910
1
FAN, 3” BOX, 120V
FA-3973
1
40
WASHER, SPLIT LOCK
WS-22300
2
20
1/2" SELF ADHESIVE GASKET
GS-2019
1
41
STAR LOCK WASHER
WS-2467
1
21
KNOB, THERMOSTAT
KN-26568
3
BONNET ASSEMBLY
A
ITEM
DESCRIPTION
PART NO. QTY ITEM
DESCRIPTION
PART NO. QTY
1
BRACKET, PILOT LIGHT MTG .
1004360
1
10
NUT, HEX #8-32
NU-2296
2
2
MIDBONNET STUD ASSEMBLY
5012095
1
11
PANEL OVERLAY - 1000
PE-29384
1
3
CABLE, WIRE HARNESS
CB-34945
1
PANEL OVERLAY - 767, 1767
PE-29361
1
4
CONTROL
CC-34488
1
12
8-32 X 1/2 PHIL SCREW
SC-2425
2
5
CONNECTOR
CR-34559
2
13
SWITCH ROCKER
SW-34769
1
6
CONNECTOR-5 CONDUCTOR
CR-34646
2
14
TIMER, 208-240V, 230V
TR-34539
1
7
KNOB, THERMOSTAT CONTROL
KN-26568
2
TIMER, 120V
TR-34540
8
WHITE PILOT LIGHT, 208-240V, 230V
LI-3951
1
15
THERMOSTAT
TT-34910
1
WHITE PILOT LIGHT, 120V
LI-3027
1
16
WASHER
WS-22300
2
9
M4-0 .7 HEX NUT 18-8
NU-22286
2
MID-BONNET ASSEMBLY
B
*
not
shown
D A N G E R
DISCONNECT UNIT FROM
POWER SOURCE BEFORE
CLEANING OR SERVICING.
D A N G E R
LOCK-OUT OR POST
BREAKER PANEL UNTIL
SERVICE WORK HAS
BEEN COMPLETED.
