Page 4 Analog Heavy-Duty Data Sheet Version: 20130507
HEA VY DUT Y INCLI NO ME T E R
ANA LOG & RS 232 I NT ER F ACE
Programmable Parameters
The parameters of inclinometer can be re-configured using the RS232 interface . Additionally Preset can
also be done through a (soon to be available) Analog Teach-in. (Refer User Manual for additional
information).
2
The resolution programming functionality is not yet fully operational.
Modes of Operation Can be switched between Polled Mode or Continuous mode.
Baud rate The Baud rate can be programmed to lie between ranges of
2400 Baud and 115200 Baud.
Output Transmission Rate The transmission rate of angular values can be adjusted to lie
between 62.5 ms and 10 seconds per value.
Moving Average Filter Used to calculate the output position value as an average over last
N values where N varies from 2 to 100 measurements in steps of
N = n², n = 1, 2, 3 …
Resolution
2
Per 1° The parameter, resolution per degree is used to program the
desired number of angular divisions per 1° of rotation.
Preset Value The current position value is set to the mid angle position by the
parameter preset.
