GENERAL Model: American Audio® CDI-500 Mp3™ - Professional CD Player
Type: Tray loading, digital compact disc audio player.
Disc type: Standard size compact discs only (5 in/12 cm and 3in/8cm)
Applicable File Extenstions for Mp3s: mp3, MP3, mP3, and Mp3
Pitch Range: Within +/- 4%, +/- 8%, +/- 16%, +/- 100%
Pitch Accuracy: 0.15%
Dimensions: 348mm (W) x 246mm (D) x 106mm (H)
Installation: Place on flat surface or mount in flat case
Weight: 8.2 Lbs. / 3.7 Kgs
Power supply: AC 115/230V, 50/60Hz
AC 100V, 50/60Hz (Japan)
AC 110V, 60Hz (Colombia)
AC 120V, 60Hz (U.S.A. and Canada)
AC 127V, 60Hz (Mexico)
AC 220V, 50Hz (Chile and Argentina)
AC 220V, 60Hz (Philippines and Korea)
AC 230V, 50Hz (Europe, New Zealand, South Africa, and Singapore)
AC 240V, 50Hz (Australia and U.K.)
Power consumption: 17W
Environmental conditions: Operational temperature: 5 to 35˚C (41 to 95˚F)
Operational humidity: 25 to 85% RH (no condensation)
Storage temperature: -20 to 60˚C (4 to 140˚F)
Accessories: Connecting RCA Cable (1 set for left and right channels)
Control 1/8” miniplug type (3 feet)
AUDIO SECTION
Quantization:
16 bit linear per channel
Sampling rate: 44.1 kHz at normal pitch
Over sampling rate: 8 times
D/A conversion 16 bit
Frequency response: +/- 1 dB 20 Hz to 20,000 Hz
Output level: 1.4V +/- 1dB
Load impedance: 47k ohm or more
AUDIO CHARACTERISTICS (TEST DISC: TCD-782, LOAD=47Kohm)
ITEM
NOMINAL LIMIT CONDITION
Output level 1.4Vrms+/-0.5dB 1.4Vrms+/-1dB 1KHz,0dB
Channel balance within 0.2dB within 1dB 1KHz,0dB
Frequency response 20Hz-20KHz, +/-0.4dB 20Hz-20KHz,+/-1dB 0dB Output
De-emphasis response +/-0.2dB +/-1dB 16KHz,-20dB
Channel separation* 90dB 85dB 1KHz,0dB
T.H.D. + NOISE*1 0.006% 0.01% 1KHz,0dB
S/N ratio (IHF-A)*2 120dB 90dB 1KHz.0dB
NOTE: 1* With 20KHz low pass filter. *2 With 20KHz low pass filter, "IHF-A" weighted
SEARCHING TIME (TEST DISC: TCD-792)
ITEM
NOMINAL LIMITS CONDITION
Short access time 2sec 4sec Play next track
Long access time 4sec 6sec Track 1 ->Track 20
Track 20 ->Track 1
PLAYABILITY
ITEM
NOMINAL LIMIT CONDITION
Interruption 1mm 0.7mm TCD-725
Black dot 1mm 0.6mm TCD-725
Finger prints 75um 65um TCD-725
Eccentricity 140um 140um TCD-712 W/O TRACK JUMP
Vertical deviation 1mm 0.5mm TCD-731R
PICK-UP
System
Object lens drive system optical pick-up
Object lens drive system 2 dimensional parallel drive
SPECIFICATIONS
© American Audio ® - www.AmericanAudio.us - CDI-500 Mp3™ Instruction Manual Page 36
