AAON M3-094 - Manual (Page 21)

Heating Coil Module Feature String Nomenclature
M
O
DULE
ID
PO
SIT
IO
N
AIRFL
O
W
EL
EC H
EAT
CAPA
CIT
Y
STA
G
IN
G
H
EAT
C
O
IL
SIZ
E
RO
WS
FPI TYPE CO
ATI
N
G
BL
ANK
B
L
AN
K
BL
ANK
BL
ANK
MOD
UL
E
AC
CE
S
S
OR
Y
ACCESS TYPE
HCD - 000 - A - H E - B B C A A - 0 0 0 0 0 - B - 0
21
Heating Coil Module Description
HEATING COIL MODULE
Module ID
HCA = Hot Water Coil, External Connections
HCB = Steam Coil, External Connections
HCC = Electric Heat
HCD = Hot Water Coil with Internal Face and
Bypass Dampers
HCE = Hot Water Coil with External Face and
Bypass Dampers
HCF = Integral Face and Bypass Hot Water Coil
HCG = Steam Coil with Internal Face and Bypass
Dampers
HCH = Steam Coil with External Face and Bypass
Dampers
HCJ = Integral Face and Bypass Steam Coil
Position
### = Level and Position of Module in Air Handling
Unit
Compartment Pressurization
0 = Blow-Through
A = Draw-Through
ELECTRIC HEAT
Capacity
0 = No Electric Heat
A = 40 kW
B = 80 kW
C = 120 kW
D = 160 kW
E = 200 kW
F = 240 kW
G = 280 kW
H = 320 kW
J = 360 kW
K = 400 kW
L = 440 kW
M = 480 kW
Staging
0 = No Electric Heat
A = 2 Stage
B = 3 Stage
C = 4 Stage
D = 6 Stage
E = 8 Stage
F = 12 Stage
G = SCR Controlled - Potentiometer
H = SCR Controlled - 0-10VDC External Control
HEATING COIL
Size
0 = No Heating Coil
A = Size A
B = Size B
C = Size C
D = Size D
Rows
0 = No Heating Coil
A = 1 Row, 1/2” Tubes
B = 2 Rows, 1/2” Tubes
C = 1 Row, 5/8” Tubes
D = 2 Rows, 5/8” Tubes
