AAON M3-094 - Manual (Page 16)

Supply Fan Module Feature String Nomenclature
M
O
DULE
ID
PO
SIT
IO
N
CONNEC
TION
CTRL
TYPE
C
T
R
L M
A
N
U
BL
WR
Q
UA
NTI
TY
BL
WR
TYPE BL
WR
H
P
BL
O
WER
BL
WR
ISOLATI
O
N
FILT
TYPE
F
IL
T
AC
CE
S
S
OR
Y
PO
WE
R
SWIT
CH
CTRL PANEL MOD
UL
E
AC
CE
S
S
OR
Y
ACCESS TYPE
SFA - 000 - 0 - 0 0 - C P H G A - A C B 0 R - B - 0
16
Blower
0 = 24” Diameter
A = 27” Diameter
B = 30” Diameter
C = 33” Diameter
D = 36.5” Diameter
E = 42.5” Diameter
Blower Isolation
0 = Springs (Unhoused 1” Deflection)
A = Springs (Unhoused 2” Deflection)
B = Springs (Seismic 1” Deflection)
C = Springs (Seismic 2” Deflection)
D = Option 0 + Backdraft Dampers
E = Option A + Backdraft Dampers
F = Option B + Backdraft Dampers
G = Option C + Backdraft Dampers
Filter Type
0 = None
A = 2” Pleated, 30% Eff, MERV 8
B = 4” Pleated, 30” Eff, MERV 8
Filter Accessories
0 = None
A = Clogged Filter Switch
B = Magnehelic Gauge
C = Options A + B
D = Air Flow Measurement
E = Options A + D
F = Options B + D
G = Options A + B + D
Power Switch
0 = No Wiring
A = Power Block (No Power Switch)
B = 60 Amp Non-fused Disconnect Switch
C = 100 Amp Non-fused Disconnect Switch
D = 150 Amp Non-fused Disconnect Switch
E = 250 Amp Non-fused Disconnect Switch
F = 400 Amp Non-fused Disconnect Switch
G = 600 Amp Non-fused Disconnect Switch
H = 60 Amp Fused Disconnect Switch
J = 100 Amp Fused Disconnect Switch
K = 150 Amp Fused Disconnect Switch
L = 250 Amp Fused Disconnect Switch
M= 400 Amp Fused Disconnect Switch
N = 600 Amp Fused Disconnect Switch
Control Panel / Opening
0 = None
A = Left Control Panel
B = Right Control Panel
C = Left Discharge Opening
D = Options B + C
E = Right Discharge Opening
F = Options A + E
G = Top Discharge Opening
H = Options A + G
I = Options B + G
