Contemporary Research
26 Display Express System Manual
The chart below covers the most common commands that can be sent via the Special Commands tool. Many more
are available from the product manual or product page at
ome commands can be sent with no
other information, such as P1 for Power On. Most other commands need an added parameter, such as volume level
or control type.
Command
Description
All Controllers
Power Off
P0
Power On
P1
Tune Analog
TC, 2-127
Example: TC,33
Tuning Format
All
S0,
0=CATV
1=Off-Air
2=IRC
3=HRC
4=Auto
Volume
VL,
Sets TV volume level
0 = Mute
1 – 63 = Minimum level (1) to maximum volume (63)
RS-232
ICC1-232, ICC2-ATSC, ICC2-VDC
Tuning Style
ICC1-232
H1= 1 = 5-digit CableCard style tuning (1-9999)
2 = Virtual HD Major-Minor tuning (tunes to virtual channel ID in display)
3 = Physical HD Major-Minor tuning (physical channel, minor digital)
HD Tuning
TH,
Example: TH,15,1 tunes channel 15-1
HD Tune Style
ICC1-232
TH,
